- Codice Macchina
- SS37
- Manufacturer
- PIZZOLATO
- Modello
- SYNCHRO
- Year
- 2008
- Larghezza (mm)
- 1600
- Lunghezza foglio
- 350-1650
- Materiali
- mapers and cardboards 50-450 g/m2
- Cicli/min
- 250m/min
- Diametro massimo bobina svolgitore
- 1500
- Ulteriori informazioni
- Sheet width 350 -1500mm. Sheet lengths: from 350 to 1650mm. Transversal blade load :700 g/m2 Rotary knives: 3 Format precision: +/- 0,5mm ( +/- 0,05% ) -measured on the sheets coming in sequence from the same roll Angle accuracy: 0,5mm measured on a1000mm sheet length Height of the pile including the pallet: 400mm- 1500mm. Reel diam. 500 -1500mm. Reel width : 400-1500mm Core diam. From 76 - 300mm. Reel weight max 2 tons. With pneumatic air cooled brakes. Register control through photocell for pre printed reels Very good conditions It can be seen in production!
| Codice Macchina | SS37 |
| Manufacturer | PIZZOLATO |
| Modello | SYNCHRO |
| Year | 2008 |
| Larghezza (mm) | 1600 |
| Lunghezza foglio | 350-1650 |
| Materiali | mapers and cardboards 50-450 g/m2 |
| Cicli/min | 250m/min |
| Diametro massimo bobina svolgitore | 1500 |
| Ulteriori informazioni | Sheet width 350 -1500mm. Sheet lengths: from 350 to 1650mm. Transversal blade load :700 g/m2 Rotary knives: 3 Format precision: +/- 0,5mm ( +/- 0,05% ) -measured on the sheets coming in sequence from the same roll Angle accuracy: 0,5mm measured on a1000mm sheet length Height of the pile including the pallet: 400mm- 1500mm. Reel diam. 500 -1500mm. Reel width : 400-1500mm Core diam. From 76 - 300mm. Reel weight max 2 tons. With pneumatic air cooled brakes. Register control through photocell for pre printed reels Very good conditions It can be seen in production! |
