- Codice Macchina
- EX553
- Manufacturer
- CMG
- Year
- 2006
- Numero di strati
- 3
- Struttura film
- ABC
- Materiali
- LDPE, LLDPE, MDPE, HDPE, PP, Metallocene, EVA, Plastomers, Ionomers, PA, PS
- Larghezza film
- 1800
- Output (Kg/h)
- 300
- Rif strati estrusore 1:
- A
- Screw diam 1
- 55
- Description 1
- 30LD, new screw installed in 2012
- Rif strati estrusore 2:
- B
- Screw diam 2
- 75
- Description 2
- 30LD, new screw installed in 2012
- Rif strati estrusore 3:
- C
- Screw diam 3
- 55
- Description 3
- 30LD, new screw installed in 2012
- Descrizione testa
- Fixed die-head
- Diamtero filiera (mm)
- 350 mm and 275 mm
- Controllo di spessore
- K-DESIGN profile measurement and control system with contact KUNDIG sensor
- Bubble cage
- Calibration cage with ultrasonic bubble control
- Panel for gussets
- Rotating take-off with collapsing frame with gusseting system (driven, controlled from main panel on ground level)
- Trattamento Corona
- VETAPHONE automatic corona treater (W/m2/min working system)
- Guida film
- E+L web guide
- Diametro massimo avvolgitore
- 1200
- Ulteriori informazioni
- -Film thickness: 17 – 250 um -4-component per extruder gravimetric system -Manual screen changers -IBC system with automatic layflat width control -Chill rolls for film cooling -Set of idle rollers -SIMCO ION antistatic system on both winders -Trim removal system -Set of 3” (76mm) and 6” (152mm) self – centering expandable air shafts -Tower included OPTIONS: -Inline trim recycling system – EXACT -Air and water chiller (Euro chiller – OFC / GCW / ABF)
| Codice Macchina | EX553 |
| Manufacturer | CMG |
| Year | 2006 |
| Numero di strati | 3 |
| Struttura film | ABC |
| Materiali | LDPE, LLDPE, MDPE, HDPE, PP, Metallocene, EVA, Plastomers, Ionomers, PA, PS |
| Larghezza film | 1800 |
| Output (Kg/h) | 300 |
| Rif strati estrusore 1: | A |
| Screw diam 1 | 55 |
| Description 1 | 30LD, new screw installed in 2012 |
| Rif strati estrusore 2: | B |
| Screw diam 2 | 75 |
| Description 2 | 30LD, new screw installed in 2012 |
| Rif strati estrusore 3: | C |
| Screw diam 3 | 55 |
| Description 3 | 30LD, new screw installed in 2012 |
| Descrizione testa | Fixed die-head |
| Diamtero filiera (mm) | 350 mm and 275 mm |
| Controllo di spessore | K-DESIGN profile measurement and control system with contact KUNDIG sensor |
| Bubble cage | Calibration cage with ultrasonic bubble control |
| Panel for gussets | Rotating take-off with collapsing frame with gusseting system (driven, controlled from main panel on ground level) |
| Trattamento Corona | VETAPHONE automatic corona treater (W/m2/min working system) |
| Guida film | E+L web guide |
| Diametro massimo avvolgitore | 1200 |
| Ulteriori informazioni | -Film thickness: 17 – 250 um -4-component per extruder gravimetric system -Manual screen changers -IBC system with automatic layflat width control -Chill rolls for film cooling -Set of idle rollers -SIMCO ION antistatic system on both winders -Trim removal system -Set of 3” (76mm) and 6” (152mm) self – centering expandable air shafts -Tower included OPTIONS: -Inline trim recycling system – EXACT -Air and water chiller (Euro chiller – OFC / GCW / ABF) |
