- Codice Macchina
- RE117
- Manufacturer
- EREMA
- Modello
- 906T / HG
- Year
- 2010
- Diametro vite (mm)
- 70
- Mulino
- Belt conveyor Width 600 mm FB 5000/600, Dust and sound proof insulation tunnel, metal detector 1140 x 400 mm, reel feeder device up to 14 m/min, toothed rollers diam 188 mm, cutter compactor power 30kw, controlling system for pre-densification
- Extruder
- Motor power 37 kw, manual screen changer CL 104 diam104 mm 4 kw, screw lenght 1300 mm, heating power 6 kw 2 zones, schock sensors, melt pressure indicator
- Degassaggio
- No
- Raffreddamento
- Hot die face pellettising system HG 82/1500, water cooling with termo regulation
- Vibrovaglio
- Yes. Pellet dewatering screen GS 1500, vibrating system dimension1400 x 300 mm
- Cyclone
- Pellet centrifugal dryer GZ 350 x 300 mm
- Output
- 380 - 230 kg
- Ulteriori informazioni
- 906 T-HG
| Codice Macchina | RE117 |
| Manufacturer | EREMA |
| Modello | 906T / HG |
| Year | 2010 |
| Diametro vite (mm) | 70 |
| Mulino | Belt conveyor Width 600 mm FB 5000/600, Dust and sound proof insulation tunnel, metal detector 1140 x 400 mm, reel feeder device up to 14 m/min, toothed rollers diam 188 mm, cutter compactor power 30kw, controlling system for pre-densification |
| Extruder | Motor power 37 kw, manual screen changer CL 104 diam104 mm 4 kw, screw lenght 1300 mm, heating power 6 kw 2 zones, schock sensors, melt pressure indicator |
| Degassaggio | No |
| Raffreddamento | Hot die face pellettising system HG 82/1500, water cooling with termo regulation |
| Vibrovaglio | Yes. Pellet dewatering screen GS 1500, vibrating system dimension1400 x 300 mm |
| Cyclone | Pellet centrifugal dryer GZ 350 x 300 mm |
| Output | 380 - 230 kg |
| Ulteriori informazioni | 906 T-HG |
