- Codice Macchina
- ST162
- Manufacturer
- TCM
- Year
- 1998
- Numero di colori
- 8
- Print possibilityes
- 8+0, 4+4, 7+1, 5+3
- Tipologia
- Reel to reel
- Larghezza nastro (mm)
- 1450
- Larghezza stampa (mm)
- 1400
- Print repeat (mm)
- 400-900 mm
- unwinder type
- Turret
- Max diameter reel unwinder (mm)
- 800
- Rewinder type
- Turret
- Max diameter reel rewinder (mm)
- 800
- Essiccazione
- Gas burner
- Videocamera
- Yes,
- Inking sysytem
- Type of inks : water
- Anilox
- 8
- Cilindri stampa
- 8 x450-500-550-600-650-700-800-900mm
- Ulteriori informazioni
- Manual longitudinal/trasversal register. Helical clichè gears type. Gear pitch 10mm; Clichè thickness 2,54 + 0,5 ; Mechanical speed150.Printing speed 120.Max power installed 60. Ink distribution : idraulic motors; Materials : HTD LTD LPD BIO. Manual positioning system; Manual printing stations blocking system ; Vertical in/out printing. Ink feeding rubber roller.Pneumatic shafts 4 (76mm). Edge guide. 1 curved spreader rolls ; 48 gears.3 roller trolley. Power of essication 100.000 Kcal.
Codice Macchina | ST162 |
Manufacturer | TCM |
Year | 1998 |
Numero di colori | 8 |
Print possibilityes | 8+0, 4+4, 7+1, 5+3 |
Tipologia | Reel to reel |
Larghezza nastro (mm) | 1450 |
Larghezza stampa (mm) | 1400 |
Print repeat (mm) | 400-900 mm |
unwinder type | Turret |
Max diameter reel unwinder (mm) | 800 |
Rewinder type | Turret |
Max diameter reel rewinder (mm) | 800 |
Essiccazione | Gas burner |
Videocamera | Yes, |
Inking sysytem | Type of inks : water |
Anilox | 8 |
Cilindri stampa | 8 x450-500-550-600-650-700-800-900mm |
Ulteriori informazioni | Manual longitudinal/trasversal register. Helical clichè gears type. Gear pitch 10mm; Clichè thickness 2,54 + 0,5 ; Mechanical speed150.Printing speed 120.Max power installed 60. Ink distribution : idraulic motors; Materials : HTD LTD LPD BIO. Manual positioning system; Manual printing stations blocking system ; Vertical in/out printing. Ink feeding rubber roller.Pneumatic shafts 4 (76mm). Edge guide. 1 curved spreader rolls ; 48 gears.3 roller trolley. Power of essication 100.000 Kcal. |
