- Maschinencode
- ST162
- Hersteller
- TCM
- Baujahr
- 1998
- Number of colors
- 8
- Print possibilityes
- 8+0, 4+4, 7+1, 5+3
- Typ
- Reel to reel
- Web width (mm)
- 1450
- Print width (mm)
- 1400
- Print repeat (mm)
- 400-900 mm
- unwinder type
- Turret
- Max diameter reel unwinder (mm)
- 800
- Rewinder type
- Turret
- Max diameter reel rewinder (mm)
- 800
- Drying
- Gas burner
- Videocamera
- Yes,
- Inking sysytem
- Type of inks : water
- Anilox
- 8
- Print cylinders
- 8 x450-500-550-600-650-700-800-900mm
- Note
- Manual longitudinal/trasversal register. Helical clichè gears type. Gear pitch 10mm; Clichè thickness 2,54 + 0,5 ; Mechanical speed150.Printing speed 120.Max power installed 60. Ink distribution : idraulic motors; Materials : HTD LTD LPD BIO. Manual positioning system; Manual printing stations blocking system ; Vertical in/out printing. Ink feeding rubber roller.Pneumatic shafts 4 (76mm). Edge guide. 1 curved spreader rolls ; 48 gears.3 roller trolley. Power of essication 100.000 Kcal.
| Maschinencode | ST162 |
| Hersteller | TCM |
| Baujahr | 1998 |
| Number of colors | 8 |
| Print possibilityes | 8+0, 4+4, 7+1, 5+3 |
| Typ | Reel to reel |
| Web width (mm) | 1450 |
| Print width (mm) | 1400 |
| Print repeat (mm) | 400-900 mm |
| unwinder type | Turret |
| Max diameter reel unwinder (mm) | 800 |
| Rewinder type | Turret |
| Max diameter reel rewinder (mm) | 800 |
| Drying | Gas burner |
| Videocamera | Yes, |
| Inking sysytem | Type of inks : water |
| Anilox | 8 |
| Print cylinders | 8 x450-500-550-600-650-700-800-900mm |
| Note | Manual longitudinal/trasversal register. Helical clichè gears type. Gear pitch 10mm; Clichè thickness 2,54 + 0,5 ; Mechanical speed150.Printing speed 120.Max power installed 60. Ink distribution : idraulic motors; Materials : HTD LTD LPD BIO. Manual positioning system; Manual printing stations blocking system ; Vertical in/out printing. Ink feeding rubber roller.Pneumatic shafts 4 (76mm). Edge guide. 1 curved spreader rolls ; 48 gears.3 roller trolley. Power of essication 100.000 Kcal. |
