- Codice Macchina
- FL840
- Manufacturer
- CARINT- C&C FLEXO
- Modello
- Cyberflex 1708
- Year
- 2007
- Numero di colori
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Cambio a maniche rapido
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Larghezza nastro (mm)
- 1270
- Larghezza stampa (mm)
- 1200
- Min print repeat (mm)
- 400
- Max print repeat (mm)
- 800
- Unwinder type
- Semi automatic with mariiage roller
- Diametro massimo svolgitore (mm)
- 800
- Rewinder type
- Automatic turret
- Max reel diameter rewinder (mm)
- 800
- Essiccazione
- 2 electric heaters by 100kw each
- Videocamera
- POWERSCOPE 3000 – 1 CHIP BST
- Guida film
- in and out
- Sistema d'inchiostro
- Doctor blade + ceramic anilox
- Anilox
- 8 sleeves. 1x100lcm 1 x140lcm, 5 x400 lcm, 1 x 240 lcm
- Maniche stampa
- n° 48 plate sleeves; repeats: 400 mm 430 mm 440 mm 460 mm 490
- Ulteriori informazioni
- Printing speed: 300m/min Max. Overall Dimensions( L x W x H) 13000 x5800 x 4700 Tension Range 2-20 kg
| Codice Macchina | FL840 |
| Manufacturer | CARINT- C&C FLEXO |
| Modello | Cyberflex 1708 |
| Year | 2007 |
| Numero di colori | 8 |
| Print possibilityes | 8+0 |
| Gearless | Yes |
| Cambio a maniche rapido | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Larghezza nastro (mm) | 1270 |
| Larghezza stampa (mm) | 1200 |
| Min print repeat (mm) | 400 |
| Max print repeat (mm) | 800 |
| Unwinder type | Semi automatic with mariiage roller |
| Diametro massimo svolgitore (mm) | 800 |
| Rewinder type | Automatic turret |
| Max reel diameter rewinder (mm) | 800 |
| Essiccazione | 2 electric heaters by 100kw each |
| Videocamera | POWERSCOPE 3000 – 1 CHIP BST |
| Guida film | in and out |
| Sistema d'inchiostro | Doctor blade + ceramic anilox |
| Anilox | 8 sleeves. 1x100lcm 1 x140lcm, 5 x400 lcm, 1 x 240 lcm |
| Maniche stampa | n° 48 plate sleeves; repeats: 400 mm 430 mm 440 mm 460 mm 490 |
| Ulteriori informazioni | Printing speed: 300m/min Max. Overall Dimensions( L x W x H) 13000 x5800 x 4700 Tension Range 2-20 kg |
