- Code Machine
- FI262
- Fabricant
- FMC/ELWA
- Modello
- EL-B-FA-1600 SL
- Année
- 1997
- Type of bags
- Garbage bags
- Working width (mm)
- 1550
- Bag length
- 200 -2500
- Bag width
- 100-1550
- Cycle / min
- 100m/min max metric speed
- Unwinder
- Machine equipped with a two position unwind with mechanical unwind shafts and braking cones. Max. roll diam. 800mm
- Note
- Bottom weld bags.Electric supply 25 kw/A. Compresses air 8 bar/1800 l/min. Photo electric eye for printed film conversion. Sealhead and infeed servo motor driven. Auto needle stacking and shingle automatic indexing table.Two folds possible with gripper fingers and supplementary folding device-bags up to 750mm long can be stacked unfolded.One continous perforation bank with 6 ball & die punches.
Code Machine | FI262 |
Fabricant | FMC/ELWA |
Modello | EL-B-FA-1600 SL |
Année | 1997 |
Type of bags | Garbage bags |
Working width (mm) | 1550 |
Bag length | 200 -2500 |
Bag width | 100-1550 |
Cycle / min | 100m/min max metric speed |
Unwinder | Machine equipped with a two position unwind with mechanical unwind shafts and braking cones. Max. roll diam. 800mm |
Note | Bottom weld bags.Electric supply 25 kw/A. Compresses air 8 bar/1800 l/min. Photo electric eye for printed film conversion. Sealhead and infeed servo motor driven. Auto needle stacking and shingle automatic indexing table.Two folds possible with gripper fingers and supplementary folding device-bags up to 750mm long can be stacked unfolded.One continous perforation bank with 6 ball & die punches. |
