- Code Machine
- SS36
- Fabricant
- VALMET STRECKER
- Modello
- EXACTA CUT WMCR/1500
- Année
- 1989
- Width (mm)
- 1500
- Sheet length
- 297-1500
- Materials
- paper 20gr/m2 - 500gr/m2
- Cycle / min
- 200m/min ; 500cuts/min
- Max diameter reel unwinder
- 1200
- Note
- Slitting system:4 Sissorknifes for Lenght Cutting; Strip inserts: 2x; Tension Knife : max 50 0gsm; Unwind system: unwinde 2xr; Core size: 76mm,152mm,300mm shaftless; Brake system: pneumatisch,automatic ; Each Unwinder with paper braking system automatik controll against diameter . For normal paper wiith steelbeam, for specialpaper with 300 mm roll.Fotocell and Ultrasonic system for cutting with printingmaterials; 8 knifes spare parts
| Code Machine | SS36 |
| Fabricant | VALMET STRECKER |
| Modello | EXACTA CUT WMCR/1500 |
| Année | 1989 |
| Width (mm) | 1500 |
| Sheet length | 297-1500 |
| Materials | paper 20gr/m2 - 500gr/m2 |
| Cycle / min | 200m/min ; 500cuts/min |
| Max diameter reel unwinder | 1200 |
| Note | Slitting system:4 Sissorknifes for Lenght Cutting; Strip inserts: 2x; Tension Knife : max 50 0gsm; Unwind system: unwinde 2xr; Core size: 76mm,152mm,300mm shaftless; Brake system: pneumatisch,automatic ; Each Unwinder with paper braking system automatik controll against diameter . For normal paper wiith steelbeam, for specialpaper with 300 mm roll.Fotocell and Ultrasonic system for cutting with printingmaterials; 8 knifes spare parts |
