- Code Machine
- FL1157
- Fabricant
- UTECO
- Modello
- DIAMOND HP 108
- Année
- 2015
- Number of colors
- 10
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1350
- Print width (mm)
- 1300
- Min print repeat (mm)
- 400
- Max print repeat (mm)
- 850
- Unwinder type
- Automatic Turret
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Automatic Turret
- Max reel diameter rewinder (mm)
- 1000
- Drying
- 2 gas burners, 2 zones, thermo oil heat exchangers - 6mt final tunnel. Automatic air recirculation system with LEL control
- Videocamera
- Yes Grafikontrol
- Corona treatment
- Ferrarini Benelli
- Web guides
- yes
- Vyscosity control
- Yes
- Washing system
- yes automatic
- Inking system
- Closed chamber doctor blades and cemaric anilox
- Anilox
- 20
- Print Sleeves
- 60
- Note
- Operator lifting platforms for sleeves change Automatic LEL control
| Code Machine | FL1157 |
| Fabricant | UTECO |
| Modello | DIAMOND HP 108 |
| Année | 2015 |
| Number of colors | 10 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1350 |
| Print width (mm) | 1300 |
| Min print repeat (mm) | 400 |
| Max print repeat (mm) | 850 |
| Unwinder type | Automatic Turret |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Automatic Turret |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | 2 gas burners, 2 zones, thermo oil heat exchangers - 6mt final tunnel. Automatic air recirculation system with LEL control |
| Videocamera | Yes Grafikontrol |
| Corona treatment | Ferrarini Benelli |
| Web guides | yes |
| Vyscosity control | Yes |
| Washing system | yes automatic |
| Inking system | Closed chamber doctor blades and cemaric anilox |
| Anilox | 20 |
| Print Sleeves | 60 |
| Note | Operator lifting platforms for sleeves change Automatic LEL control |
