- Code Machine
- FL1085
- Fabricant
- WINDMÖLLER & HÖLSCHER
- Modello
- PRIMAFLEX CL8
- Année
- 2010
- Number of colors
- 8
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1320
- Print width (mm)
- 1270
- Min print repeat (mm)
- 370
- Max print repeat (mm)
- 1070
- Unwinder type
- Turret non stop
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret non stop
- Max reel diameter rewinder (mm)
- 1000
- Drying
- Gas drying. 2 Burners 4 fans. Automatic air recirculation system with ENPRO LEL system
- Videocamera
- BST ELTROMAT Year 2022, model IPQ 100% inspection
- Vyscosity control
- Yes automatic Ink Spec
- Washing system
- Automatic Washing system Turbo clean
- Inking system
- Closed chamber doctor blades
- Anilox
- 8
- Print Sleeves
- 8
- Note
- mechanical speed 400m/min Easy set: automatic print pressure setting Easy reg: automatic register setting
| Code Machine | FL1085 |
| Fabricant | WINDMÖLLER & HÖLSCHER |
| Modello | PRIMAFLEX CL8 |
| Année | 2010 |
| Number of colors | 8 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1320 |
| Print width (mm) | 1270 |
| Min print repeat (mm) | 370 |
| Max print repeat (mm) | 1070 |
| Unwinder type | Turret non stop |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Turret non stop |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | Gas drying. 2 Burners 4 fans. Automatic air recirculation system with ENPRO LEL system |
| Videocamera | BST ELTROMAT Year 2022, model IPQ 100% inspection |
| Vyscosity control | Yes automatic Ink Spec |
| Washing system | Automatic Washing system Turbo clean |
| Inking system | Closed chamber doctor blades |
| Anilox | 8 |
| Print Sleeves | 8 |
| Note | mechanical speed 400m/min Easy set: automatic print pressure setting Easy reg: automatic register setting |
