- Code Machine
- FL1037
- Fabricant
- UTECO
- Modello
- EMERALD
- Année
- 2007
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1350
- Print width (mm)
- 1300
- Min print repeat (mm)
- 380
- Max print repeat (mm)
- 800
- Unwinder type
- Turret
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret
- Max reel diameter rewinder (mm)
- 1000
- Drying
- 2 zones 4 fans , 4 mt tunnel 2 gas burners
- Videocamera
- Yes BST
- Corona treatment
- No
- Web guides
- yes in and out
- Vyscosity control
- yes
- Anilox
- 30
- Print Sleeves
- 8x350mm ,360;370;380;390;400;410;420;440;450;460;480;500;520;530;540;550;560;570;580;600;620;640;650;660;680mm
- Note
- Speed 400mpm
| Code Machine | FL1037 |
| Fabricant | UTECO |
| Modello | EMERALD |
| Année | 2007 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1350 |
| Print width (mm) | 1300 |
| Min print repeat (mm) | 380 |
| Max print repeat (mm) | 800 |
| Unwinder type | Turret |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Turret |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | 2 zones 4 fans , 4 mt tunnel 2 gas burners |
| Videocamera | Yes BST |
| Corona treatment | No |
| Web guides | yes in and out |
| Vyscosity control | yes |
| Anilox | 30 |
| Print Sleeves | 8x350mm ,360;370;380;390;400;410;420;440;450;460;480;500;520;530;540;550;560;570;580;600;620;640;650;660;680mm |
| Note | Speed 400mpm |
