- Code Machine
- FL964
- Fabricant
- COMEXI
- Modello
- FB2108 CNC GL
- Année
- 2004
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1270
- Print width (mm)
- 1220
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 850
- Unwinder type
- TURRET AUTOMATIC NON STOP WITH ROLL LIFTING SYSTEM
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- TURRET AUTOMATIC NON STOP WITH ROLL LIFTING SYSTEM
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 Zones 4 fans steam heat exchangesr
- Videocamera
- Yes
- Corona treatment
- Corona, AHLBRANDT type ASOH 21V- E
- Web guides
- Yes in and out BST OPG
- Vyscosity control
- 8 automatic BLOSS
- Washing system
- Yes Automatic
- Inking system
- Closed chamber doctor blades
- Anilox
- over 20
- Print Sleeves
- 10 x 440,10 x 480, 10 x 580, 7 x 580, 10 x 640 (plate thickness
- Note
- Slitting on rewinder (x5), banana roll, 4 x extra chamber doctor blades,
Code Machine | FL964 |
Fabricant | COMEXI |
Modello | FB2108 CNC GL |
Année | 2004 |
Number of colors | 8 |
Print possibilityes | 8+0 |
Gearless | Yes |
Fast sleeve change | Yes |
4 motor per deck CNC position system | Yes |
Computer supervision | Yes |
Web width (mm) | 1270 |
Print width (mm) | 1220 |
Min print repeat (mm) | 350 |
Max print repeat (mm) | 850 |
Unwinder type | TURRET AUTOMATIC NON STOP WITH ROLL LIFTING SYSTEM |
Max reel diameter unwinder (mm) | 800 |
Rewinder type | TURRET AUTOMATIC NON STOP WITH ROLL LIFTING SYSTEM |
Max reel diameter rewinder (mm) | 800 |
Drying | 2 Zones 4 fans steam heat exchangesr |
Videocamera | Yes |
Corona treatment | Corona, AHLBRANDT type ASOH 21V- E |
Web guides | Yes in and out BST OPG |
Vyscosity control | 8 automatic BLOSS |
Washing system | Yes Automatic |
Inking system | Closed chamber doctor blades |
Anilox | over 20 |
Print Sleeves | 10 x 440,10 x 480, 10 x 580, 7 x 580, 10 x 640 (plate thickness |
Note | Slitting on rewinder (x5), banana roll, 4 x extra chamber doctor blades, |
