- Code Machine
- FL822
- Fabricant
- UTECO
- Modello
- ONYX 808
- Année
- 2014
- Number of colors
- 8
- Print possibilityes
- 8+0 , with reprint possibility
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1350
- Print width (mm)
- 1300
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 800
- Unwinder type
- Turret Automatic
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 1000
- Drying
- 2 zones , 4 fans , final tunnel 4 mt , 2 gas burners
- Videocamera
- Yes
- Corona treatment
- Yes
- Web guides
- Yes in and out
- Vyscosity control
- Yes
- Washing system
- Yes fully auto wash up system
- Anilox
- 12
- Print Sleeves
- 50
| Code Machine | FL822 |
| Fabricant | UTECO |
| Modello | ONYX 808 |
| Année | 2014 |
| Number of colors | 8 |
| Print possibilityes | 8+0 , with reprint possibility |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1350 |
| Print width (mm) | 1300 |
| Min print repeat (mm) | 350 |
| Max print repeat (mm) | 800 |
| Unwinder type | Turret Automatic |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | 2 zones , 4 fans , final tunnel 4 mt , 2 gas burners |
| Videocamera | Yes |
| Corona treatment | Yes |
| Web guides | Yes in and out |
| Vyscosity control | Yes |
| Washing system | Yes fully auto wash up system |
| Anilox | 12 |
| Print Sleeves | 50 |
