- Code Machine
- FL825
- Fabricant
- UTECO
- Modello
- AMETHIST 808 1M
- Année
- 2003
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- No
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- No
- Computer supervision
- Yes
- Web width (mm)
- 1250
- Print width (mm)
- 1200
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 800
- Unwinder type
- Turret
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 800
- Drying
- Electric
- Videocamera
- BST Genius
- Web guides
- Yes BST
- Vyscosity control
- Yes, Fasnacht
- Note
- Gears with 5mm pitch Tension range: 2.5 - 40 Kg
Code Machine | FL825 |
Fabricant | UTECO |
Modello | AMETHIST 808 1M |
Année | 2003 |
Number of colors | 8 |
Print possibilityes | 8+0 |
Gearless | No |
Fast sleeve change | Yes |
4 motor per deck CNC position system | No |
Computer supervision | Yes |
Web width (mm) | 1250 |
Print width (mm) | 1200 |
Min print repeat (mm) | 350 |
Max print repeat (mm) | 800 |
Unwinder type | Turret |
Max reel diameter unwinder (mm) | 800 |
Rewinder type | Turret automatic |
Max reel diameter rewinder (mm) | 800 |
Drying | Electric |
Videocamera | BST Genius |
Web guides | Yes BST |
Vyscosity control | Yes, Fasnacht |
Note | Gears with 5mm pitch Tension range: 2.5 - 40 Kg |
