- Code Machine
- FL707
- Fabricant
- FLEXOTECNICA
- Modello
- TACHIS
- Année
- 2000
- Number of colors
- 9
- Print possibilityes
- 8 flexo + 1 gravure downstream
- Gearless
- No
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Web width (mm)
- 1250
- Print width (mm)
- 1200
- Min print repeat (mm)
- 300
- Max print repeat (mm)
- 650
- Unwinder type
- Turret automtic
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones 2 thermo oil heat exchangers
- Videocamera
- Yes Eltromat
- Corona treatment
- Yes AFS
- Web guides
- yes in and out
- Vyscosity control
- Yes New Celio
- Inking system
- Closed chamber Doctor blades
- Anilox
- 12 ceramic anilox sleeves
- Print Sleeves
- 248 print sleeves, 8 for each repeat 300 , 310, 320, 325, 330, 340, 350, 360, 370,375, 380, 390,400,410,420,430, 440,450,460,470,480,490,500,520,530,540,550,560,570,580, 600
- Print cylinders
- 2 sets of carriers
- Note
- Gravure coating unit in line
| Code Machine | FL707 |
| Fabricant | FLEXOTECNICA |
| Modello | TACHIS |
| Année | 2000 |
| Number of colors | 9 |
| Print possibilityes | 8 flexo + 1 gravure downstream |
| Gearless | No |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Web width (mm) | 1250 |
| Print width (mm) | 1200 |
| Min print repeat (mm) | 300 |
| Max print repeat (mm) | 650 |
| Unwinder type | Turret automtic |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 zones 2 thermo oil heat exchangers |
| Videocamera | Yes Eltromat |
| Corona treatment | Yes AFS |
| Web guides | yes in and out |
| Vyscosity control | Yes New Celio |
| Inking system | Closed chamber Doctor blades |
| Anilox | 12 ceramic anilox sleeves |
| Print Sleeves | 248 print sleeves, 8 for each repeat 300 , 310, 320, 325, 330, 340, 350, 360, 370,375, 380, 390,400,410,420,430, 440,450,460,470,480,490,500,520,530,540,550,560,570,580, 600 |
| Print cylinders | 2 sets of carriers |
| Note | Gravure coating unit in line |
