SCHIAVI PATRIOT Maquina de grabado 8 colores

Código Máquina
RO147
Constructor
SCHIAVI
Modello
PATRIOT
Año
1995
Number of colors
8
Print possibilities
7+1, 8+0
Drive
Cardan
Trolley system
Yes
Web width (mm)
1430
Print width (mm)
1400
Print repeat range (mm)
400-1000 mm
Drying specifications
units 1 to 7 , 1 blowing fan each unit , single drying hood 2, 5 mt , and one main exhaust fan ; for unt 8 double drying hood 2 x 2,,5 mt , 1 blowing and 1 exhaust . Automatic air recirculation unit with LEL control by Nira for all units
Drying heat surce
Thermo oil heaters
Unwinder type
Turret Automatic
Max reel diameter unwinder (mm)
1000
Rewinder type
Turret Automatic
Max reel diameter rewinder (mm)
1000
Videocamera
BST
Register controll
BOBST S 3100
Vyscosity control
8 automatic Selectra
Corona treatment
yes by MERO
Print cylinders
300
Note
14 trolleys Fire protection system on all units
Código Máquina RO147
Constructor SCHIAVI
Modello PATRIOT
Año 1995
Number of colors 8
Print possibilities 7+1, 8+0
Drive Cardan
Trolley system Yes
Web width (mm) 1430
Print width (mm) 1400
Print repeat range (mm) 400-1000 mm
Drying specifications units 1 to 7 , 1 blowing fan each unit , single drying hood 2, 5 mt , and one main exhaust fan ; for unt 8 double drying hood 2 x 2,,5 mt , 1 blowing and 1 exhaust . Automatic air recirculation unit with LEL control by Nira for all units
Drying heat surce Thermo oil heaters
Unwinder type Turret Automatic
Max reel diameter unwinder (mm) 1000
Rewinder type Turret Automatic
Max reel diameter rewinder (mm) 1000
Videocamera BST
Register controll BOBST S 3100
Vyscosity control 8 automatic Selectra
Corona treatment yes by MERO
Print cylinders 300
Note 14 trolleys Fire protection system on all units
