- Código Máquina
- FL630
- Constructor
- UTECO
- Modello
- ONYX 107
- Año
- 2010
- Number of colors
- 10
- Print possibilityes
- 10+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1250
- Print width (mm)
- 1200
- Min print repeat (mm)
- 330
- Max print repeat (mm)
- 800
- Unwinder type
- Turret automatic
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones , 4 fans , 5 mt tunnel , two gas burners 150.000 kcal /h
- Videocamera
- BST Premius digital with register control
- Web guides
- yes in and out
- Vyscosity control
- yes 8 automatic
- Washing system
- yes automatic wash up system for closed chamber doctor blades and anilox
- Inking system
- Solvent based
- Anilox
- 10 anilox ceramic sleeves
- Print Sleeves
- to be agreed
- Note
- Mechanical speed 400m/min renovation 2020
| Código Máquina | FL630 |
| Constructor | UTECO |
| Modello | ONYX 107 |
| Año | 2010 |
| Number of colors | 10 |
| Print possibilityes | 10+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1250 |
| Print width (mm) | 1200 |
| Min print repeat (mm) | 330 |
| Max print repeat (mm) | 800 |
| Unwinder type | Turret automatic |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 zones , 4 fans , 5 mt tunnel , two gas burners 150.000 kcal /h |
| Videocamera | BST Premius digital with register control |
| Web guides | yes in and out |
| Vyscosity control | yes 8 automatic |
| Washing system | yes automatic wash up system for closed chamber doctor blades and anilox |
| Inking system | Solvent based |
| Anilox | 10 anilox ceramic sleeves |
| Print Sleeves | to be agreed |
| Note | Mechanical speed 400m/min renovation 2020 |
