- Código Máquina
- FL1120
- Constructor
- WINDMÖLLER & HÖLSCHER
- Modello
- Olympia
- Año
- 1982
- Number of colors
- 6
- Print possibilityes
- 5 flexo +1 gravure
- Overhaul/renovation
- Yes, in 1999. Several upgrded parts (e.g. web inspection)
- Gearless
- No
- Fast sleeve change
- No
- 4 motor per deck CNC position system
- No
- Computer supervision
- No
- Web width (mm)
- 1135
- Print width (mm)
- 1080
- Unwinder type
- Turret automatic
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 1000
- Drying
- 4 hot air drying hoods up to 150 degrees
- Videocamera
- FUTEC auto print inspection
- Print Sleeves
- 67 thou x 127 - 112 thou x 22
- Note
- 5mm gear pitch Print Viewing -webscope scanner Oil manderel system 7 Air Manderels 3 Spare Air sleeves 7 Pneumatic Pumps Available as optional for additional price: Microdot Mounter Heaford (2011) Plate Making Equipment - UV developer and plate washer
| Código Máquina | FL1120 |
| Constructor | WINDMÖLLER & HÖLSCHER |
| Modello | Olympia |
| Año | 1982 |
| Number of colors | 6 |
| Print possibilityes | 5 flexo +1 gravure |
| Overhaul/renovation | Yes, in 1999. Several upgrded parts (e.g. web inspection) |
| Gearless | No |
| Fast sleeve change | No |
| 4 motor per deck CNC position system | No |
| Computer supervision | No |
| Web width (mm) | 1135 |
| Print width (mm) | 1080 |
| Unwinder type | Turret automatic |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | 4 hot air drying hoods up to 150 degrees |
| Videocamera | FUTEC auto print inspection |
| Print Sleeves | 67 thou x 127 - 112 thou x 22 |
| Note | 5mm gear pitch Print Viewing -webscope scanner Oil manderel system 7 Air Manderels 3 Spare Air sleeves 7 Pneumatic Pumps Available as optional for additional price: Microdot Mounter Heaford (2011) Plate Making Equipment - UV developer and plate washer |
