COMEXI FW1508 Impresora Flexo 8 colores

Código Máquina
FL903
Constructor
COMEXI
Modello
FW1508
Año
2010
Number of colors
8
Print possibilityes
8+0
Gearless
Yes
Fast sleeve change
Yes
4 motor per deck CNC position system
Yes
Computer supervision
Yes
Web width (mm)
1320
Print width (mm)
1270
Min print repeat (mm)
380
Max print repeat (mm)
800
Unwinder type
Turret Automatic non stop with Electric Roll lifting device
Max reel diameter unwinder (mm)
1000
Rewinder type
Turret Automatic non stop with Electric Roll lifting device
Max reel diameter rewinder (mm)
1000
Drying
2 zones , final drying tunnel 4,5 mt length with 14 blowing air slots, 2 electric heaters ech one power 126 kW. LEL controls
Videocamera
AVT Print Vision Jupiter Dual mode
Corona treatment
Yes AFS
Web guides
Yes in and out BST type OPG
Washing system
Yes automatic
Inking system
Closed chamber doctor blades with magnetic blade locking
Anilox
Carbon fiber anilox mandrels - 10 ceramic anilox sleeves ; 2 x340 l/cm, 2 x 320 l/cm , 2 x 140 l/cm , 1x 160 l/cm, 1x 120 l/cm
Print Sleeves
64 sleeve s and 1 set of carbon fiber carriers ; repeat 7 x380mm, 8x 400mm , 8x 420 mm, 8x 480mm, 8x 520 mm, 8x 600mm , 8x 620 mm, 8x 680mm,
Note
Hastalloy plasma coated drum Gearless direct drive system Automatic print final setting PRESCO ACONPRO Uninterrupted power supply unit ( UPS ) Temperature control unit complete with One water chiller of 18.500 frig/h. (21 KW) capacity. Capacity suitable for chill rollers, as well as for the CI drum temperature stabiliser.
Código Máquina FL903
Constructor COMEXI
Modello FW1508
Año 2010
Number of colors 8
Print possibilityes 8+0
Gearless Yes
Fast sleeve change Yes
4 motor per deck CNC position system Yes
Computer supervision Yes
Web width (mm) 1320
Print width (mm) 1270
Min print repeat (mm) 380
Max print repeat (mm) 800
Unwinder type Turret Automatic non stop with Electric Roll lifting device
Max reel diameter unwinder (mm) 1000
Rewinder type Turret Automatic non stop with Electric Roll lifting device
Max reel diameter rewinder (mm) 1000
Drying 2 zones , final drying tunnel 4,5 mt length with 14 blowing air slots, 2 electric heaters ech one power 126 kW. LEL controls
Videocamera AVT Print Vision Jupiter Dual mode
Corona treatment Yes AFS
Web guides Yes in and out BST type OPG
Washing system Yes automatic
Inking system Closed chamber doctor blades with magnetic blade locking
Anilox Carbon fiber anilox mandrels - 10 ceramic anilox sleeves ; 2 x340 l/cm, 2 x 320 l/cm , 2 x 140 l/cm , 1x 160 l/cm, 1x 120 l/cm
Print Sleeves 64 sleeve s and 1 set of carbon fiber carriers ; repeat 7 x380mm, 8x 400mm , 8x 420 mm, 8x 480mm, 8x 520 mm, 8x 600mm , 8x 620 mm, 8x 680mm,
Note Hastalloy plasma coated drum Gearless direct drive system Automatic print final setting PRESCO ACONPRO Uninterrupted power supply unit ( UPS ) Temperature control unit complete with One water chiller of 18.500 frig/h. (21 KW) capacity. Capacity suitable for chill rollers, as well as for the CI drum temperature stabiliser.
** SOLD **
