- Código Máquina
- FL797
- Constructor
- UTECO
- Modello
- EMERALD 812 4M
- Año
- 2010
- Number of colors
- 8
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1650
- Print width (mm)
- 1600
- Max print repeat (mm)
- 1250
- Unwinder type
- TURRET with flying splice
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- TURRET with flying splice
- Max reel diameter rewinder (mm)
- 1000
- Drying
- Gas
- Videocamera
- BST Premius camera
- Corona treatment
- Provision for corona system
- Web guides
- BST edge guide
- Vyscosity control
- Fasnacht viscosity control
- Washing system
- Yes
- Inking system
- Type of inks: solvent based
- Anilox
- Anilox sleeves 15
- Print Sleeves
- Carrier sleeves x 24
- Print cylinders
- Printing sleeves approximately: 140
- Note
- Airshafts for winder: 2 x 76mm, 2 x 152mm Maximum mechanical speed: 450m/min
| Código Máquina | FL797 |
| Constructor | UTECO |
| Modello | EMERALD 812 4M |
| Año | 2010 |
| Number of colors | 8 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1650 |
| Print width (mm) | 1600 |
| Max print repeat (mm) | 1250 |
| Unwinder type | TURRET with flying splice |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | TURRET with flying splice |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | Gas |
| Videocamera | BST Premius camera |
| Corona treatment | Provision for corona system |
| Web guides | BST edge guide |
| Vyscosity control | Fasnacht viscosity control |
| Washing system | Yes |
| Inking system | Type of inks: solvent based |
| Anilox | Anilox sleeves 15 |
| Print Sleeves | Carrier sleeves x 24 |
| Print cylinders | Printing sleeves approximately: 140 |
| Note | Airshafts for winder: 2 x 76mm, 2 x 152mm Maximum mechanical speed: 450m/min |
