- Maschinencode
- LA471
- Hersteller
- ROTOMEC
- Modello
- M2
- Baujahr
- 1984
- Application
- Coating
- Type of lamination/coating
- SOLVENT / WATER BASED
- Overhaul/renovation
- yes, in 2021
- Working width (mm)
- 1135
- Speed
- 200mpm
- First unwinder type
- Turret automatic
- Max diameter reel unwinder
- 1000
- Rewinder type
- Turret automatic
- Max diameter reel rewinder
- 1000
- Coating unit
- 1 gravure units
- Drying
- 4 hot air drying up to 150 degrees. Horizontal tunnel
- Note
- Rotomec air sleeve system NDC Coatwieght Scanner NDC Moister scanner Dr Schenk Web Detection 13 Spare cylinders 30 Spare Pressure Sleeves Water heating System - Tricol Lacquer Mix System - Spiroflow, including Hoppers, Screws and 2 holding tanks Safety Scanner unwind/rewind - 2 top, 2 bottom
| Maschinencode | LA471 |
| Hersteller | ROTOMEC |
| Modello | M2 |
| Baujahr | 1984 |
| Application | Coating |
| Type of lamination/coating | SOLVENT / WATER BASED |
| Overhaul/renovation | yes, in 2021 |
| Working width (mm) | 1135 |
| Speed | 200mpm |
| First unwinder type | Turret automatic |
| Max diameter reel unwinder | 1000 |
| Rewinder type | Turret automatic |
| Max diameter reel rewinder | 1000 |
| Coating unit | 1 gravure units |
| Drying | 4 hot air drying up to 150 degrees. Horizontal tunnel |
| Note | Rotomec air sleeve system NDC Coatwieght Scanner NDC Moister scanner Dr Schenk Web Detection 13 Spare cylinders 30 Spare Pressure Sleeves Water heating System - Tricol Lacquer Mix System - Spiroflow, including Hoppers, Screws and 2 holding tanks Safety Scanner unwind/rewind - 2 top, 2 bottom |
