- Maschinencode
- LA245
- Hersteller
- NORDMECCANICA
- Modello
- TRIPLEX LAMINATOR
- Baujahr
- 2006
- Application
- Triplex lamination
- Type of lamination/coating
- SOLVENT / WATER BASED
- Working width (mm)
- 1520
- Materials
- Paper/Foil/Film ,Paper gsm - 20gsm to 150gsm , foil 7 to 20 micron all plastic film
- Speed
- 275m/min
- First unwinder type
- Turret automatic
- Max diameter reel unwinder
- 1200
- Secondary unwinder type
- two single position single unwinder roll diam 1000 mm for foil and film on Hot Melt coating unit
- Max diameter reel unwinder
- 1000
- Third unwinder type
- Turret automatic
- Max diameter reel unwinder
- 1000
- Rewinder type
- Turret automatic
- Max diameter reel rewinder
- 1270
- Coating unit
- Water based using semi-flexo and rotogravure-solvent based adhesive
- Second Coating unitr
- Hotmelt adhesive die using EVA or PSA hotmelt adhesive
- Third Coating unit
- Solventless adhesive (single or two component)
Maschinencode | LA245 |
Hersteller | NORDMECCANICA |
Modello | TRIPLEX LAMINATOR |
Baujahr | 2006 |
Application | Triplex lamination |
Type of lamination/coating | SOLVENT / WATER BASED |
Working width (mm) | 1520 |
Materials | Paper/Foil/Film ,Paper gsm - 20gsm to 150gsm , foil 7 to 20 micron all plastic film |
Speed | 275m/min |
First unwinder type | Turret automatic |
Max diameter reel unwinder | 1200 |
Secondary unwinder type | two single position single unwinder roll diam 1000 mm for foil and film on Hot Melt coating unit |
Max diameter reel unwinder | 1000 |
Third unwinder type | Turret automatic |
Max diameter reel unwinder | 1000 |
Rewinder type | Turret automatic |
Max diameter reel rewinder | 1270 |
Coating unit | Water based using semi-flexo and rotogravure-solvent based adhesive |
Second Coating unitr | Hotmelt adhesive die using EVA or PSA hotmelt adhesive |
Third Coating unit | Solventless adhesive (single or two component) |
