- Maschinencode
- FL1003
- Hersteller
- FISCHER & KRECKE
- Modello
- FLEXPRESS 6S-8
- Baujahr
- 2008
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1300
- Print width (mm)
- 1250
- Min print repeat (mm)
- 320
- Max print repeat (mm)
- 800
- Unwinder type
- Turret automatic with roll loading table
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret automatic with roll unloading table
- Max reel diameter rewinder (mm)
- 1000
- Drying
- 2 zones 4 fans 5 mt tunnel and 2 Gas burners
- Videocamera
- ELTROMAT 3000 video system for continuous viewing and NSTALLED ON 2013 GRAFIKONTROL Grafikscan 3000
- Corona treatment
- AFS corona treater
- Vyscosity control
- Automatic viscosity control system - Bloss type 1000
- Washing system
- Complete F&K AUTO CLEAN system
- Anilox
- 21 ceramic anilox sleeves
- Print Sleeves
- 300 printing sleeves between 320 and 680 mm repeat
- Note
- 2 antistatic bars
Maschinencode | FL1003 |
Hersteller | FISCHER & KRECKE |
Modello | FLEXPRESS 6S-8 |
Baujahr | 2008 |
Number of colors | 8 |
Print possibilityes | 8+0 |
Gearless | Yes |
Fast sleeve change | Yes |
4 motor per deck CNC position system | Yes |
Computer supervision | Yes |
Web width (mm) | 1300 |
Print width (mm) | 1250 |
Min print repeat (mm) | 320 |
Max print repeat (mm) | 800 |
Unwinder type | Turret automatic with roll loading table |
Max reel diameter unwinder (mm) | 1000 |
Rewinder type | Turret automatic with roll unloading table |
Max reel diameter rewinder (mm) | 1000 |
Drying | 2 zones 4 fans 5 mt tunnel and 2 Gas burners |
Videocamera | ELTROMAT 3000 video system for continuous viewing and NSTALLED ON 2013 GRAFIKONTROL Grafikscan 3000 |
Corona treatment | AFS corona treater |
Vyscosity control | Automatic viscosity control system - Bloss type 1000 |
Washing system | Complete F&K AUTO CLEAN system |
Anilox | 21 ceramic anilox sleeves |
Print Sleeves | 300 printing sleeves between 320 and 680 mm repeat |
Note | 2 antistatic bars |
