- Maschinencode
- FL834
- Hersteller
- COMEXI
- Modello
- FJ 2108
- Baujahr
- 2004
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- No
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1270
- Print width (mm)
- 1220
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 850
- Unwinder type
- Turret semi automatic marriage roll
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret automatic flying splice
- Max reel diameter rewinder (mm)
- 800
- Drying
- Gas, between colors and drying tunnel
- Videocamera
- AVT 2009 - camera with dual screens
- Web guides
- BST type OPG before printing and rewinding
- Vyscosity control
- LR products 2004
- Inking system
- 8 pneumatic reversible ink pumps
- Print Sleeves
- yes
- Note
- Speed 300m/min subject to web, materials, printing, inks Electricity 3 x 400 V, 50 Hz Products to be printed Films LDPE 25-150 my, PP, OPP 12-30 my Unwind Turret, marriage roll, dancing roller, tension control, pneumatic shaft 3”and 6” Rewind Turret non-stop, pneumatic shaft 3” Printing unit 8 colours, slow rotation with electrical motors, chamber doctor blades, through off system, meshing system Longitudinal register /side register : Motorized Drive system Bull gear, gear-pitch 5 mm
| Maschinencode | FL834 |
| Hersteller | COMEXI |
| Modello | FJ 2108 |
| Baujahr | 2004 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | No |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1270 |
| Print width (mm) | 1220 |
| Min print repeat (mm) | 350 |
| Max print repeat (mm) | 850 |
| Unwinder type | Turret semi automatic marriage roll |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Turret automatic flying splice |
| Max reel diameter rewinder (mm) | 800 |
| Drying | Gas, between colors and drying tunnel |
| Videocamera | AVT 2009 - camera with dual screens |
| Web guides | BST type OPG before printing and rewinding |
| Vyscosity control | LR products 2004 |
| Inking system | 8 pneumatic reversible ink pumps |
| Print Sleeves | yes |
| Note | Speed 300m/min subject to web, materials, printing, inks Electricity 3 x 400 V, 50 Hz Products to be printed Films LDPE 25-150 my, PP, OPP 12-30 my Unwind Turret, marriage roll, dancing roller, tension control, pneumatic shaft 3”and 6” Rewind Turret non-stop, pneumatic shaft 3” Printing unit 8 colours, slow rotation with electrical motors, chamber doctor blades, through off system, meshing system Longitudinal register /side register : Motorized Drive system Bull gear, gear-pitch 5 mm |
