- Machine code
- FL903
- Manufacturer
- COMEXI
- Modello
- FW1508
- Year
- 2010
- Number of colors
- 8
- Print possibilityes
- 8+0
- Gearless
- Yes
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1320
- Print width (mm)
- 1270
- Min print repeat (mm)
- 380
- Max print repeat (mm)
- 800
- Unwinder type
- Turret Automatic non stop with Electric Roll lifting device
- Max reel diameter unwinder (mm)
- 1000
- Rewinder type
- Turret Automatic non stop with Electric Roll lifting device
- Max reel diameter rewinder (mm)
- 1000
- Drying
- 2 zones , final drying tunnel 4,5 mt length with 14 blowing air slots, 2 electric heaters ech one power 126 kW. LEL controls
- Videocamera
- AVT Print Vision Jupiter Dual mode
- Corona treatment
- Yes AFS
- Web guides
- Yes in and out BST type OPG
- Washing system
- Yes automatic
- Inking system
- Closed chamber doctor blades with magnetic blade locking
- Anilox
- Carbon fiber anilox mandrels - 10 ceramic anilox sleeves ; 2 x340 l/cm, 2 x 320 l/cm , 2 x 140 l/cm , 1x 160 l/cm, 1x 120 l/cm
- Print Sleeves
- 64 sleeve s and 1 set of carbon fiber carriers ; repeat 7 x380mm, 8x 400mm , 8x 420 mm, 8x 480mm, 8x 520 mm, 8x 600mm , 8x 620 mm, 8x 680mm,
- Note
- Hastalloy plasma coated drum Gearless direct drive system Automatic print final setting PRESCO ACONPRO Uninterrupted power supply unit ( UPS ) Temperature control unit complete with One water chiller of 18.500 frig/h. (21 KW) capacity. Capacity suitable for chill rollers, as well as for the CI drum temperature stabiliser.
| Machine code | FL903 |
| Manufacturer | COMEXI |
| Modello | FW1508 |
| Year | 2010 |
| Number of colors | 8 |
| Print possibilityes | 8+0 |
| Gearless | Yes |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1320 |
| Print width (mm) | 1270 |
| Min print repeat (mm) | 380 |
| Max print repeat (mm) | 800 |
| Unwinder type | Turret Automatic non stop with Electric Roll lifting device |
| Max reel diameter unwinder (mm) | 1000 |
| Rewinder type | Turret Automatic non stop with Electric Roll lifting device |
| Max reel diameter rewinder (mm) | 1000 |
| Drying | 2 zones , final drying tunnel 4,5 mt length with 14 blowing air slots, 2 electric heaters ech one power 126 kW. LEL controls |
| Videocamera | AVT Print Vision Jupiter Dual mode |
| Corona treatment | Yes AFS |
| Web guides | Yes in and out BST type OPG |
| Washing system | Yes automatic |
| Inking system | Closed chamber doctor blades with magnetic blade locking |
| Anilox | Carbon fiber anilox mandrels - 10 ceramic anilox sleeves ; 2 x340 l/cm, 2 x 320 l/cm , 2 x 140 l/cm , 1x 160 l/cm, 1x 120 l/cm |
| Print Sleeves | 64 sleeve s and 1 set of carbon fiber carriers ; repeat 7 x380mm, 8x 400mm , 8x 420 mm, 8x 480mm, 8x 520 mm, 8x 600mm , 8x 620 mm, 8x 680mm, |
| Note | Hastalloy plasma coated drum Gearless direct drive system Automatic print final setting PRESCO ACONPRO Uninterrupted power supply unit ( UPS ) Temperature control unit complete with One water chiller of 18.500 frig/h. (21 KW) capacity. Capacity suitable for chill rollers, as well as for the CI drum temperature stabiliser. |
