DE BERNARDI DB100N SH Saldatrice per sacchetti Soft loop handles // Film bag making // Bag making // Macchine Flexo Usate // Tecno Converting 2000 S.r.l.

Codice Macchina: FI521
Manufacturer: DE BERNARDI
Modello: DB100N SH
Year: 2007
Type of delivery: Conveyor table
Type of handle: Multiple (patch and softloop)
Type of sealing/bags: Side weld
Tipo di sacchetti: Soft loop handles
Larghezza lavoro (mm): 850
Numero di piste: 1
Lunghezza sacchetti: 250-800
Larghezza sacchetti: 250-800
Cicli/min: 100-120
Svolgitore: Single shafted motor braked. Width 1600mm
Ulteriori informazioni: Flexo-loop bags w/wo bottom gusset Flexo-loop bags with reinforcement turn-up w/wo bottom gusset Die cut handle bags Die cut handle bags with reinforcement turn-up Material that can be processed:LDPE,HDPE, and recycled extracts Max welding width: Up to 850 mm Sealing width (bag length): 250-800mm Draw length (bag width): 250-800 mm Handle width: 30mm loop thickness:180-230 micron Driving system: PLC controlled Operator interface terminal Print registration control Servo motor driven input nip rollers 2 sealing bars, 1 for side and 1 for bottom seal

Codice Macchina	FI521
Manufacturer	DE BERNARDI
Modello	DB100N SH
Year	2007
Type of delivery	Conveyor table
Type of handle	Multiple (patch and softloop)
Type of sealing/bags	Side weld
Tipo di sacchetti	Soft loop handles
Larghezza lavoro (mm)	850
Numero di piste	1
Lunghezza sacchetti	250-800
Larghezza sacchetti	250-800
Cicli/min	100-120
Svolgitore	Single shafted motor braked. Width 1600mm
Ulteriori informazioni	Flexo-loop bags w/wo bottom gusset Flexo-loop bags with reinforcement turn-up w/wo bottom gusset Die cut handle bags Die cut handle bags with reinforcement turn-up Material that can be processed:LDPE,HDPE, and recycled extracts Max welding width: Up to 850 mm Sealing width (bag length): 250-800mm Draw length (bag width): 250-800 mm Handle width: 30mm loop thickness:180-230 micron Driving system: PLC controlled Operator interface terminal Print registration control Servo motor driven input nip rollers 2 sealing bars, 1 for side and 1 for bottom seal
