- Codice Macchina
- LA256
- Manufacturer
- SCHIAVI
- Modello
- CONVERJET
- Applicazione
- Duplex lamination
- Tipo di accoppiamento/spalmatura
- COMBI / INTECHANGEABLE TROLLEY
- Rinnovo
- 2015 new electric cabinet PLC and drives . PLC Siemens S7-1500, Drives Siemens Simatic , new tension controls at unwinders and rewinder, new HMI Siemens
- Larghezza lavoro (mm)
- 1280
- Tipo svolgitore primario
- Turret automatic
- Diametro massimo bobina svolgitore
- 800
- Tipo svolgitore secondario
- Turret automatic
- Diametro massimo bobina svolgitore
- 800
- Rewinder type
- Turret automatic
- Diametro massimo bobina avvolgitore
- 800
- Unità di spalmatura
- Trolley based supplied with gravure trolle and semiflxo trolley
- Essiccazione
- 4 zones drying system 4 blowing fans two exhaust fans, 4 heating units, tunnel 10 mt long in 4 sections , Steam heating heat exchangers
- Trattamento Corona
- yes Ferrarini Benelli
- Coating rollers
- 4 engraved anilox gravure rollers,
- Ulteriori informazioni
- Sleeve change on coating nip roller 100 sleeves Nira LEL Supplied with Rotogravure and Semiflexo trolley Solventless trolley not available INTERCHANGEABLE TROLLEY
Codice Macchina | LA256 |
Manufacturer | SCHIAVI |
Modello | CONVERJET |
Applicazione | Duplex lamination |
Tipo di accoppiamento/spalmatura | COMBI / INTECHANGEABLE TROLLEY |
Rinnovo | 2015 new electric cabinet PLC and drives . PLC Siemens S7-1500, Drives Siemens Simatic , new tension controls at unwinders and rewinder, new HMI Siemens |
Larghezza lavoro (mm) | 1280 |
Tipo svolgitore primario | Turret automatic |
Diametro massimo bobina svolgitore | 800 |
Tipo svolgitore secondario | Turret automatic |
Diametro massimo bobina svolgitore | 800 |
Rewinder type | Turret automatic |
Diametro massimo bobina avvolgitore | 800 |
Unità di spalmatura | Trolley based supplied with gravure trolle and semiflxo trolley |
Essiccazione | 4 zones drying system 4 blowing fans two exhaust fans, 4 heating units, tunnel 10 mt long in 4 sections , Steam heating heat exchangers |
Trattamento Corona | yes Ferrarini Benelli |
Coating rollers | 4 engraved anilox gravure rollers, |
Ulteriori informazioni | Sleeve change on coating nip roller 100 sleeves Nira LEL Supplied with Rotogravure and Semiflexo trolley Solventless trolley not available INTERCHANGEABLE TROLLEY |
NORDMECCANICA SUPERSIMPLEX
-
Codice Macchina: LA304
-
Year: 1996
-
Larghezza lavoro (mm): 1400
NORDMECCANICA SIMPLEX COMBI
-
Codice Macchina: LA336
-
Year: 1996
-
Larghezza lavoro (mm): 1300
CONVERTECH PRIMER AND LAMINATING
-
Codice Macchina: LA290
-
Year: 2018
-
Larghezza lavoro (mm): 1650
NORDMECCANICA
-
Codice Macchina: LA280
-
Year: 1998
-
Larghezza lavoro (mm): 1220
ROTOMEC B 700
-
Codice Macchina: LA272
-
Year: 2004
-
Larghezza lavoro (mm): 1400
ITALFLEX 2000-80
-
Codice Macchina: LA391
-
Year: 2001
-
Larghezza lavoro (mm): 900
