- Codice Macchina
- CA276
- Manufacturer
- SML
- Modello
- Cast Ellm Monoaxial stretch
- Year
- 1999
- Numero di strati
- 1
- Struttura film
- A
- Materiali
- Diapers backsheet LDPE
- Larghezza film (mm)
- 1850
- Velocità (m/m)
- 210m/min
- Output (Kg/h)
- 350kg/h
- Rif strati estrusore 1:
- A
- Screw diam 1
- 120mm
- Description 1
- Gravimetric Dosing unit INOEX 4 components, DC motor, 120 L/D 33bimetal Double hydraulic screen change
- Descrizione testa
- made Nordson, -Type: AOM III-100/40 // RB60//MF8, gap 1mm, Die: automatic thickness control via flexlip and 82 therma bolts, edge pinning Eltex
- Die width (mm)
- Die width 2475mm Useful max melt extrusion width 2040mm Min. melt extr width 1800 mm
- Unità chill roll
- diameter 400mm, Air knife
- Controllo di spessore
- SYNTEL WIX - Electronic Systems,SCAN A & SCAN B, year 2012. One gauge before mdo and one after
- Trattamento Corona
- Me.Ro
- Rewinder max reel diameter (mm)
- 600mm
- Descrizione avvolgitore
- turret with automatic reel inloading and new cores loading HSW series Efficient 350-2600 speed 400m/min Shafted, 3" and 6" cores Max Roll Diam. 600 mm
- Ulteriori informazioni
- MDO drawing unit Max draw ratio 1: 10 Mdo water heated. Water thermoregulation included and renovater 2018 Materials : PP, LDPE / LLDPE, LLDPE with CaCO3 Continuous visual system - hole sensing - type Flexin, Electronic system Defect control system from Electronic system year 2023 Hot embossing unit in line
| Codice Macchina | CA276 |
| Manufacturer | SML |
| Modello | Cast Ellm Monoaxial stretch |
| Year | 1999 |
| Numero di strati | 1 |
| Struttura film | A |
| Materiali | Diapers backsheet LDPE |
| Larghezza film (mm) | 1850 |
| Velocità (m/m) | 210m/min |
| Output (Kg/h) | 350kg/h |
| Rif strati estrusore 1: | A |
| Screw diam 1 | 120mm |
| Description 1 | Gravimetric Dosing unit INOEX 4 components, DC motor, 120 L/D 33bimetal Double hydraulic screen change |
| Descrizione testa | made Nordson, -Type: AOM III-100/40 // RB60//MF8, gap 1mm, Die: automatic thickness control via flexlip and 82 therma bolts, edge pinning Eltex |
| Die width (mm) | Die width 2475mm Useful max melt extrusion width 2040mm Min. melt extr width 1800 mm |
| Unità chill roll | diameter 400mm, Air knife |
| Controllo di spessore | SYNTEL WIX - Electronic Systems,SCAN A & SCAN B, year 2012. One gauge before mdo and one after |
| Trattamento Corona | Me.Ro |
| Rewinder max reel diameter (mm) | 600mm |
| Descrizione avvolgitore | turret with automatic reel inloading and new cores loading HSW series Efficient 350-2600 speed 400m/min Shafted, 3" and 6" cores Max Roll Diam. 600 mm |
| Ulteriori informazioni | MDO drawing unit Max draw ratio 1: 10 Mdo water heated. Water thermoregulation included and renovater 2018 Materials : PP, LDPE / LLDPE, LLDPE with CaCO3 Continuous visual system - hole sensing - type Flexin, Electronic system Defect control system from Electronic system year 2023 Hot embossing unit in line |
