- Codice Macchina
- CA209
- Manufacturer
- SML
- Year
- 2016
- Numero di strati
- 5
- Struttura film
- a-b-c-b-a
- Materiali
- Stretch film LLDPE
- Larghezza film (mm)
- 1500
- Velocità (m/m)
- 650
- Output (Kg/h)
- approx 890Kg/h, depending on thicknesses and raw materials
- Rif strati estrusore 1:
- A
- Screw diam 1
- 90mm 33 L/D
- Description 1
- 800 Kg/h synchro gravimetric blenders
- Rif strati estrusore 2:
- B
- Screw diam 2
- 60mm 28 L/D
- Description 2
- 190 Kg/h synchro gravimetric blenders
- Rif strati estrusore 3:
- C
- Screw diam 3
- 60mm 28 L/D
- Description 3
- 190 Kg/h synchro gravimetric blenders
- Descrizione testa
- ClorenAutomatic thickness profile contol
- Die width (mm)
- 2000
- Unità chill roll
- Diamenter 1200mm , width 2100mm
- Controllo di spessore
- Electronic system
- Guida film
- Oshilating frame
- Descrizione avvolgitore
- Rewinder for hand, machine and jumbo reels, possible on 2" cores for hand reels and 3" cores for machine and jumbo reels. Reel width : 3 X 500mm / 2 X 750mm
| Codice Macchina | CA209 |
| Manufacturer | SML |
| Year | 2016 |
| Numero di strati | 5 |
| Struttura film | a-b-c-b-a |
| Materiali | Stretch film LLDPE |
| Larghezza film (mm) | 1500 |
| Velocità (m/m) | 650 |
| Output (Kg/h) | approx 890Kg/h, depending on thicknesses and raw materials |
| Rif strati estrusore 1: | A |
| Screw diam 1 | 90mm 33 L/D |
| Description 1 | 800 Kg/h synchro gravimetric blenders |
| Rif strati estrusore 2: | B |
| Screw diam 2 | 60mm 28 L/D |
| Description 2 | 190 Kg/h synchro gravimetric blenders |
| Rif strati estrusore 3: | C |
| Screw diam 3 | 60mm 28 L/D |
| Description 3 | 190 Kg/h synchro gravimetric blenders |
| Descrizione testa | ClorenAutomatic thickness profile contol |
| Die width (mm) | 2000 |
| Unità chill roll | Diamenter 1200mm , width 2100mm |
| Controllo di spessore | Electronic system |
| Guida film | Oshilating frame |
| Descrizione avvolgitore | Rewinder for hand, machine and jumbo reels, possible on 2" cores for hand reels and 3" cores for machine and jumbo reels. Reel width : 3 X 500mm / 2 X 750mm |
