- Code Machine
- RO266
- Fabricant
- SCHIAVI
- Modello
- CONCORDE
- Année
- 1991
- Number of colors
- 9
- Print possibilities
- 9 + 0 6 + 3
- Overhaul/renovation
- Yes
- Drive
- Cardan
- Trolley system
- Yes
- Web width (mm)
- 1350
- Print width (mm)
- 1300
- Print repeat range (mm)
- 450 - 900 mm
- Unwinder type
- double
- Rewinder type
- single
- Videocamera
- Defect detection AVT , no 100% only single image
- Register controll
- BST front side , Eltromat back side
- Vyscosity control
- Opticolor Visco
- Corona treatment
- 2 x Ahlbrand
- Note
- Paper 30 - 160 gsm Film 12 - 12 micron Speed 350 m/min. Printing 9 +0 , 6+3 , also laminating Turning unit PU 6/7 with seperate. web tension control Separate drive PU 1 to 9 Bobst S 5100 Inline Lamination LF + LH – HS/KS Profile coating Defect detection AVT - no 100% - only single image 2 x Corona station (Ahlbrand) 2 x Jumbo dryer PU 8+9 2 x Double dryer PU 1+7 Enulec Static all Printing units Backside camera Eltromat WebCamera BST Viscosity control :Opticolor Web edge control Erhard+Leimer 3 Back printing Trolleys, 1 Lamination Charge Trolley Slitting Station possible And other equipment e.g. Rubber impression rollers ca. 180 pc.
| Code Machine | RO266 |
| Fabricant | SCHIAVI |
| Modello | CONCORDE |
| Année | 1991 |
| Number of colors | 9 |
| Print possibilities | 9 + 0 6 + 3 |
| Overhaul/renovation | Yes |
| Drive | Cardan |
| Trolley system | Yes |
| Web width (mm) | 1350 |
| Print width (mm) | 1300 |
| Print repeat range (mm) | 450 - 900 mm |
| Unwinder type | double |
| Rewinder type | single |
| Videocamera | Defect detection AVT , no 100% only single image |
| Register controll | BST front side , Eltromat back side |
| Vyscosity control | Opticolor Visco |
| Corona treatment | 2 x Ahlbrand |
| Note | Paper 30 - 160 gsm Film 12 - 12 micron Speed 350 m/min. Printing 9 +0 , 6+3 , also laminating Turning unit PU 6/7 with seperate. web tension control Separate drive PU 1 to 9 Bobst S 5100 Inline Lamination LF + LH – HS/KS Profile coating Defect detection AVT - no 100% - only single image 2 x Corona station (Ahlbrand) 2 x Jumbo dryer PU 8+9 2 x Double dryer PU 1+7 Enulec Static all Printing units Backside camera Eltromat WebCamera BST Viscosity control :Opticolor Web edge control Erhard+Leimer 3 Back printing Trolleys, 1 Lamination Charge Trolley Slitting Station possible And other equipment e.g. Rubber impression rollers ca. 180 pc. |
