- Código Máquina
- SR656
- Constructor
- TEMAC
- Modello
- SRP 162
- Año
- 2024
- Working width (mm)
- 1600
- Unwinder type
- Shaftless
- Max diameter reel unwinder
- 1300
- Rewinder type
- Double turret center driven
- Max diameter reel rewinder
- 800
- Min slit width
- 20mm
- Note
- TOTAL OIL FREE core of 70 mm, 76,2 mm Locking by pneumatic expandable spindles servo assisted by double solenoid valve Integrated electro mechanic system managed by A.C. servo motor driven by full digital inverter for the VERTICAL mother roll lifting. Fully digital FIFE D MAX2 edge and print guide system driven by microprocessor. FIFE photo sensor “FIFE SE 26B” for edge or print line reader with automatic adjustable contrast Totally automatic system for stopping the machine without loss of material passage (tracking) with computerized management implemented via TOUCH PANEL PC
| Código Máquina | SR656 |
| Constructor | TEMAC |
| Modello | SRP 162 |
| Año | 2024 |
| Working width (mm) | 1600 |
| Unwinder type | Shaftless |
| Max diameter reel unwinder | 1300 |
| Rewinder type | Double turret center driven |
| Max diameter reel rewinder | 800 |
| Min slit width | 20mm |
| Note | TOTAL OIL FREE core of 70 mm, 76,2 mm Locking by pneumatic expandable spindles servo assisted by double solenoid valve Integrated electro mechanic system managed by A.C. servo motor driven by full digital inverter for the VERTICAL mother roll lifting. Fully digital FIFE D MAX2 edge and print guide system driven by microprocessor. FIFE photo sensor “FIFE SE 26B” for edge or print line reader with automatic adjustable contrast Totally automatic system for stopping the machine without loss of material passage (tracking) with computerized management implemented via TOUCH PANEL PC |
