- Código Máquina
- FL803
- Constructor
- UTECO
- Modelo
- EMERALD 107
- Año
- 2003
- Número de colores
- 10
- Posibilidades de impresión
- 10+Solventless lamination
- Modernización
- Major overhaul during 2016-1017, new washing system, new chamber doctor blades, new viscosity control, new videocamera, check up of bearings, mandrels re-balancing, part of sleeves and aniloxes were bought new in 2017.
- Gearless
- Yes
- Cambio rápido mangas impresión
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Ancho del material (mm)
- 1250
- Print width (mm)
- 1200
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 800
- Unwinder type
- Turret automatic
- Diámetro máximo bobinas Desenrollador (mm)
- 1000
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 800
- Sistema de secado
- 2 drying zones- 4 fans- final tunnel 6 mt length, hot water heat exchangers , automatic recirculation system with Heck controll
- Videocámera
- yes BST Eltromat new 2016, secon bd video camera E&L for back side inspection
- Corona treatment
- yes two Corona treaters F&B one before printing , second for secondary unwinder for material to be laminated
- Alineadores
- yes
- Vyscosity control
- yes new Gama 2017
- Washing system
- yes
- Sistema de tinta
- doctor blades - new 2016
- Anilox
- 40 ceramic anilox sleeves
- Mangas de impresión
- 800 totally
- Informaciones adicionales
- 10 color CI with solventless lamination in line
Código Máquina | FL803 |
Constructor | UTECO |
Modelo | EMERALD 107 |
Año | 2003 |
Número de colores | 10 |
Posibilidades de impresión | 10+Solventless lamination |
Modernización | Major overhaul during 2016-1017, new washing system, new chamber doctor blades, new viscosity control, new videocamera, check up of bearings, mandrels re-balancing, part of sleeves and aniloxes were bought new in 2017. |
Gearless | Yes |
Cambio rápido mangas impresión | Yes |
4 motor per deck CNC position system | Yes |
Computer supervision | Yes |
Ancho del material (mm) | 1250 |
Print width (mm) | 1200 |
Min print repeat (mm) | 350 |
Max print repeat (mm) | 800 |
Unwinder type | Turret automatic |
Diámetro máximo bobinas Desenrollador (mm) | 1000 |
Rewinder type | Turret automatic |
Max reel diameter rewinder (mm) | 800 |
Sistema de secado | 2 drying zones- 4 fans- final tunnel 6 mt length, hot water heat exchangers , automatic recirculation system with Heck controll |
Videocámera | yes BST Eltromat new 2016, secon bd video camera E&L for back side inspection |
Corona treatment | yes two Corona treaters F&B one before printing , second for secondary unwinder for material to be laminated |
Alineadores | yes |
Vyscosity control | yes new Gama 2017 |
Washing system | yes |
Sistema de tinta | doctor blades - new 2016 |
Anilox | 40 ceramic anilox sleeves |
Mangas de impresión | 800 totally |
Informaciones adicionales | 10 color CI with solventless lamination in line |
