- Machine code
- FI262
- Manufacturer
- FMC/ELWA
- Modello
- EL-B-FA-1600 SL
- Year
- 1997
- Type of bags
- Garbage bags
- Working width (mm)
- 1550
- Bag length
- 200 -2500
- Bag width
- 100-1550
- Cycle / min
- 100m/min max metric speed
- Unwinder
- Machine equipped with a two position unwind with mechanical unwind shafts and braking cones. Max. roll diam. 800mm
- Note
- Bottom weld bags.Electric supply 25 kw/A. Compresses air 8 bar/1800 l/min. Photo electric eye for printed film conversion. Sealhead and infeed servo motor driven. Auto needle stacking and shingle automatic indexing table.Two folds possible with gripper fingers and supplementary folding device-bags up to 750mm long can be stacked unfolded.One continous perforation bank with 6 ball & die punches.
| Machine code | FI262 |
| Manufacturer | FMC/ELWA |
| Modello | EL-B-FA-1600 SL |
| Year | 1997 |
| Type of bags | Garbage bags |
| Working width (mm) | 1550 |
| Bag length | 200 -2500 |
| Bag width | 100-1550 |
| Cycle / min | 100m/min max metric speed |
| Unwinder | Machine equipped with a two position unwind with mechanical unwind shafts and braking cones. Max. roll diam. 800mm |
| Note | Bottom weld bags.Electric supply 25 kw/A. Compresses air 8 bar/1800 l/min. Photo electric eye for printed film conversion. Sealhead and infeed servo motor driven. Auto needle stacking and shingle automatic indexing table.Two folds possible with gripper fingers and supplementary folding device-bags up to 750mm long can be stacked unfolded.One continous perforation bank with 6 ball & die punches. |
ELBA SA90-11-HP
-
Machine code: FI507
-
Year: 2001
-
Working width (mm): 1100
AMUTEC TSC/B 1800
-
Machine code: FI514
-
Year: 2002
-
Working width (mm): 1800
DE BERNARDI DB 804 RB
-
Machine code: FI523
-
Year: 1990
-
Bag width: 850
MOBERT ROLLER 6 M
-
Machine code: FI530
-
Year: 1995
-
Working width (mm): 1100
BA.S.FF HORUS 1100
-
Machine code: FI574
-
Year: 2002
-
Working width (mm): 1100
GUR-IS
-
Machine code: FI568
-
Year: 2005
-
Working width (mm): 1100
