- Machine code
- CA176
- Manufacturer
- DOLCI EXTRUSION
- Year
- 2007
- Number of layers
- 3
- Film structure
- ABC
- Material
- Stretch film LLDPE
- Film width (mm)
- 2000
- Speed (m/min)
- 600 m/min
- Output (Kg/h)
- 990 kg/h
- Extruder 1 Layer ref:
- A
- Description 1
- Innoplast dosing unit
- Extruder 2 Layer ref:
- B
- Description 2
- Innoplast dosing unit
- Extruder 3 Layer ref:
- C
- Description 3
- Innoplast dosing unit
- Head description
- CLOEREN with internal deckling
- Die width (mm)
- 2950
- Thickness controll system
- NDC
- Web guide
- Yes
- Rewinder max reel diameter (mm)
- 200 on 50 and 76mm cores. 3 shafts each winder. 21 sec/cycle
- Rewinder description
- Double 1000mm wide for hand and machine rolls. Max roll weight 17 Kg.
- Note
- Layer Distribution 25/50/25, 20/60/20, 15/70/15 with continuous adjustment Water Pumping unit with 2000 l tank
| Machine code | CA176 |
| Manufacturer | DOLCI EXTRUSION |
| Year | 2007 |
| Number of layers | 3 |
| Film structure | ABC |
| Material | Stretch film LLDPE |
| Film width (mm) | 2000 |
| Speed (m/min) | 600 m/min |
| Output (Kg/h) | 990 kg/h |
| Extruder 1 Layer ref: | A |
| Description 1 | Innoplast dosing unit |
| Extruder 2 Layer ref: | B |
| Description 2 | Innoplast dosing unit |
| Extruder 3 Layer ref: | C |
| Description 3 | Innoplast dosing unit |
| Head description | CLOEREN with internal deckling |
| Die width (mm) | 2950 |
| Thickness controll system | NDC |
| Web guide | Yes |
| Rewinder max reel diameter (mm) | 200 on 50 and 76mm cores. 3 shafts each winder. 21 sec/cycle |
| Rewinder description | Double 1000mm wide for hand and machine rolls. Max roll weight 17 Kg. |
| Note | Layer Distribution 25/50/25, 20/60/20, 15/70/15 with continuous adjustment Water Pumping unit with 2000 l tank |
