- Machine code
- FL490
- Manufacturer
- CARINT
- Modello
- GEMINI S 12
- Year
- 1989
- Number of colors
- 6
- Overhaul/renovation
- RENOVATED IN 2004
- Gearless
- No
- Fast sleeve change
- No
- Web width (mm)
- 1050
- Print width (mm)
- 1000
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 800
- Unwinder type
- TURRET
- Rewinder type
- TURRET
- Drying
- THERMAL OIL or HOT WATER THROUGH 2 HEAT EXCHANGERS
- Web guides
- 2
- Inking system
- 6 doctor blades;
- Anilox
- 11 pieces: 4x 100L/cm, 2x120, 2x160, 1x200, 2x220L/cm
- Print cylinders
- 57 pieces , plate 2.54mm printing cylinders/gears : 4 x 400mm; 6x 420mm; 5x430mm; 6x550mm; 6x560mm; 6x640mm; 6x660mm; 6x680mm; 6x720mm; 6x730mm
- Note
- Mechanical Speed : max 200m/min. Dimensions L x H x W : 9x 4x 2,6m; Cooling unit; Drying section tunnel and between colours drying;
| Machine code | FL490 |
| Manufacturer | CARINT |
| Modello | GEMINI S 12 |
| Year | 1989 |
| Number of colors | 6 |
| Overhaul/renovation | RENOVATED IN 2004 |
| Gearless | No |
| Fast sleeve change | No |
| Web width (mm) | 1050 |
| Print width (mm) | 1000 |
| Min print repeat (mm) | 350 |
| Max print repeat (mm) | 800 |
| Unwinder type | TURRET |
| Rewinder type | TURRET |
| Drying | THERMAL OIL or HOT WATER THROUGH 2 HEAT EXCHANGERS |
| Web guides | 2 |
| Inking system | 6 doctor blades; |
| Anilox | 11 pieces: 4x 100L/cm, 2x120, 2x160, 1x200, 2x220L/cm |
| Print cylinders | 57 pieces , plate 2.54mm printing cylinders/gears : 4 x 400mm; 6x 420mm; 5x430mm; 6x550mm; 6x560mm; 6x640mm; 6x660mm; 6x680mm; 6x720mm; 6x730mm |
| Note | Mechanical Speed : max 200m/min. Dimensions L x H x W : 9x 4x 2,6m; Cooling unit; Drying section tunnel and between colours drying; |
