- Machine code
- FL658
- Manufacturer
- UTECO
- Modello
- EMERALD
- Year
- 2000
- Number of colors
- 8
- Gearless
- No
- Fast sleeve change
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Web width (mm)
- 1250
- Print width (mm)
- 1200
- Min print repeat (mm)
- 330
- Max print repeat (mm)
- 750
- Unwinder type
- Two position drop splice
- Max reel diameter unwinder (mm)
- 800
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 800
- Drying
- 2 zones 4 fans , 4mt tunnel
- Inking system
- Solvent based
- Note
- Pitch 10mm Total plate thickness 2.84 + 0.38 mm Materials to be printed: HDPE 30my ,width500mm ; Pet 12my, width 550mm; BOPP, CAST PP, PP, MEt, Cellophan, Paper
| Machine code | FL658 |
| Manufacturer | UTECO |
| Modello | EMERALD |
| Year | 2000 |
| Number of colors | 8 |
| Gearless | No |
| Fast sleeve change | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Web width (mm) | 1250 |
| Print width (mm) | 1200 |
| Min print repeat (mm) | 330 |
| Max print repeat (mm) | 750 |
| Unwinder type | Two position drop splice |
| Max reel diameter unwinder (mm) | 800 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 800 |
| Drying | 2 zones 4 fans , 4mt tunnel |
| Inking system | Solvent based |
| Note | Pitch 10mm Total plate thickness 2.84 + 0.38 mm Materials to be printed: HDPE 30my ,width500mm ; Pet 12my, width 550mm; BOPP, CAST PP, PP, MEt, Cellophan, Paper |
