- Codice Macchina
- SO282
- Manufacturer
- CURIONI
- Modello
- SUN MASTER 540
- Year
- 1998
- Larghezza (mm)
- 540
- Materiali
- Paper 80 to 130 g/m2
- Alimentazione:
- Reel fed
- Maniglia
- Twisted
- Lunghezza max (mm) sacchetto
- 650
- Lunghezza min (mm) sacchetto
- 320
- Larghezza max(mm) sacchetto
- 540
- Larghezza min (mm) sacchetto
- 220
- Larghezza fondo max (mm) sacchetto
- 200
- Larghezza fondo min (mm) sacchetto
- 80
- Cicli/min
- 6000 bags/hour
- Svolgitore
- 1500mm . Mono-type with pneumatics shafts: 70 et 76 mm .Lifting device
- Ulteriori informazioni
- Cutting lenght 400-780mm Reels width 720 to 1430mm Infeed unit avec length gluing device Insertion unit - Gluing and positioning for paper twisted handles Gusset and tube forming table. Main frame with cutting, creasing and bottom opening devices Gluing and bottom closing section Counting table unit Possibility to product bags without handles Main Motor, Vacuum pump Former gears: x10 Photocell device control for pre-printed reels
| Codice Macchina | SO282 |
| Manufacturer | CURIONI |
| Modello | SUN MASTER 540 |
| Year | 1998 |
| Larghezza (mm) | 540 |
| Materiali | Paper 80 to 130 g/m2 |
| Alimentazione: | Reel fed |
| Maniglia | Twisted |
| Lunghezza max (mm) sacchetto | 650 |
| Lunghezza min (mm) sacchetto | 320 |
| Larghezza max(mm) sacchetto | 540 |
| Larghezza min (mm) sacchetto | 220 |
| Larghezza fondo max (mm) sacchetto | 200 |
| Larghezza fondo min (mm) sacchetto | 80 |
| Cicli/min | 6000 bags/hour |
| Svolgitore | 1500mm . Mono-type with pneumatics shafts: 70 et 76 mm .Lifting device |
| Ulteriori informazioni | Cutting lenght 400-780mm Reels width 720 to 1430mm Infeed unit avec length gluing device Insertion unit - Gluing and positioning for paper twisted handles Gusset and tube forming table. Main frame with cutting, creasing and bottom opening devices Gluing and bottom closing section Counting table unit Possibility to product bags without handles Main Motor, Vacuum pump Former gears: x10 Photocell device control for pre-printed reels |
