- Codice Macchina
- LA246
- Manufacturer
- ROTOMEC
- Modello
- Coater and laminator
- Year
- 1990
- Applicazione
- Triplex lamination
- Tipo di accoppiamento/spalmatura
- SOLVENT / WATER BASED
- Rinnovo
- New drives ControlTechnique and electric renovation
- Larghezza lavoro (mm)
- 1450
- Materiali
- Plastic film; Alu foil and paper up to 120gsm
- Velocità
- 300 mt/min
- Tipo svolgitore primario
- Turret
- Diametro massimo bobina svolgitore
- 800
- Tipo svolgitore secondario
- Turret
- Diametro massimo bobina svolgitore
- 800
- Tipo terzo svolgitore
- Single for Alu foil
- Diametro massimo bobina svolgitore
- 800
- Rewinder type
- Turret automatic center surface by Cerruti new 2010
- Diametro massimo bobina avvolgitore
- 1000
- Unità di spalmatura
- Gravure type
- Seconda unità di spalmatura
- Gravure type
- Essiccazione
- Diathermic oil-2 sections - first tunnel 4 mt after coating unit, second tunnel 12 mt after second coating unit
- Trattamento Corona
- 2 corona treaters
- Ulteriori informazioni
- Operation possibilities: -double coating front side -double coating font and back side -lamination and coating on front or back side -triplex lamination CERUTTI turret rewinder center surface new 2010
Codice Macchina | LA246 |
Manufacturer | ROTOMEC |
Modello | Coater and laminator |
Year | 1990 |
Applicazione | Triplex lamination |
Tipo di accoppiamento/spalmatura | SOLVENT / WATER BASED |
Rinnovo | New drives ControlTechnique and electric renovation |
Larghezza lavoro (mm) | 1450 |
Materiali | Plastic film; Alu foil and paper up to 120gsm |
Velocità | 300 mt/min |
Tipo svolgitore primario | Turret |
Diametro massimo bobina svolgitore | 800 |
Tipo svolgitore secondario | Turret |
Diametro massimo bobina svolgitore | 800 |
Tipo terzo svolgitore | Single for Alu foil |
Diametro massimo bobina svolgitore | 800 |
Rewinder type | Turret automatic center surface by Cerruti new 2010 |
Diametro massimo bobina avvolgitore | 1000 |
Unità di spalmatura | Gravure type |
Seconda unità di spalmatura | Gravure type |
Essiccazione | Diathermic oil-2 sections - first tunnel 4 mt after coating unit, second tunnel 12 mt after second coating unit |
Trattamento Corona | 2 corona treaters |
Ulteriori informazioni | Operation possibilities: -double coating front side -double coating font and back side -lamination and coating on front or back side -triplex lamination CERUTTI turret rewinder center surface new 2010 |
