- Codice Macchina
- LAB77
- Manufacturer
- EDALE
- Modello
- BETA 250
- Year
- 2004
- Numero di colori
- 8
- Larghezza nastro (mm)
- 240
- Larghezza stampa (mm)
- 246
- Essiccazione
- UV dryers x 8 .2 rotary die stations for Edale and Gallus tooling
- Avvolgitore
- Waste matrix rewind .Product rewind: 750mm
- Ulteriori informazioni
- Unwinders x 2, one at the beginning of the press and the second unwind after unit . Web tension unit x 2 with splicing table .E+L web guide x 2 Turner bar . Print units 6 + 2 with bridge to pass the first web on top of the two units .Laminating unit . Press is 14 meters long x 1.5 metres wide Add the foot print of the four UV cabinets, that are 1 meter behind the machine, each cabinet is 0.8 x 0.8 meter .When the machine is running with full UV, the power requirement is: 90 A, 3 x 400v + N +Earth Anilox 15
| Codice Macchina | LAB77 |
| Manufacturer | EDALE |
| Modello | BETA 250 |
| Year | 2004 |
| Numero di colori | 8 |
| Larghezza nastro (mm) | 240 |
| Larghezza stampa (mm) | 246 |
| Essiccazione | UV dryers x 8 .2 rotary die stations for Edale and Gallus tooling |
| Avvolgitore | Waste matrix rewind .Product rewind: 750mm |
| Ulteriori informazioni | Unwinders x 2, one at the beginning of the press and the second unwind after unit . Web tension unit x 2 with splicing table .E+L web guide x 2 Turner bar . Print units 6 + 2 with bridge to pass the first web on top of the two units .Laminating unit . Press is 14 meters long x 1.5 metres wide Add the foot print of the four UV cabinets, that are 1 meter behind the machine, each cabinet is 0.8 x 0.8 meter .When the machine is running with full UV, the power requirement is: 90 A, 3 x 400v + N +Earth Anilox 15 |
