- Codice Macchina
- RO264
- Manufacturer
- UTECO
- Modello
- Q- S PRESS 8
- Year
- 2007
- Numero di colori
- 8
- Possibilità stampa
- 8+0
- Motorizzazione
- Electronic shaft
- Trolley system
- Yes
- Larghezza nastro (mm)
- 1030
- Larghezza stampa (mm)
- 1015
- Formato stampa (mm)
- 440 -1000
- Drying specifications
- unit 1- 1 blowing fan single drying hood 2,8 mt length , units 2 to 7 , each unit one blowing fan , single hood 2 mt length , Unit 8 ,Double hood 2x 2,8 mt 2 blowing fans .
- Drying heat surce
- Thermo oil heat exchangers
- Unwinder type
- Turret Automatic non stop 1000 mm
- Diametro massimo svolgitore (mm)
- 1000
- Rewinder type
- Turret automatic non stop
- Max reel diameter rewinder (mm)
- 1000
- Videocamera
- Yes BST
- Controllo di registro
- YES gRAFYKONTROL
- Vyscosity control
- Yes automatic by Gama
- Ulteriori informazioni
- Press for short runs and fast change over Printing mandrels with Rotogravure quick sleeve change Possibility to us thin sleeves with Carriers or sleeve cylinders with quick change over Electrostatic assistance on station 1 to 7 by ACE
| Codice Macchina | RO264 |
| Manufacturer | UTECO |
| Modello | Q- S PRESS 8 |
| Year | 2007 |
| Numero di colori | 8 |
| Possibilità stampa | 8+0 |
| Motorizzazione | Electronic shaft |
| Trolley system | Yes |
| Larghezza nastro (mm) | 1030 |
| Larghezza stampa (mm) | 1015 |
| Formato stampa (mm) | 440 -1000 |
| Drying specifications | unit 1- 1 blowing fan single drying hood 2,8 mt length , units 2 to 7 , each unit one blowing fan , single hood 2 mt length , Unit 8 ,Double hood 2x 2,8 mt 2 blowing fans . |
| Drying heat surce | Thermo oil heat exchangers |
| Unwinder type | Turret Automatic non stop 1000 mm |
| Diametro massimo svolgitore (mm) | 1000 |
| Rewinder type | Turret automatic non stop |
| Max reel diameter rewinder (mm) | 1000 |
| Videocamera | Yes BST |
| Controllo di registro | YES gRAFYKONTROL |
| Vyscosity control | Yes automatic by Gama |
| Ulteriori informazioni | Press for short runs and fast change over Printing mandrels with Rotogravure quick sleeve change Possibility to us thin sleeves with Carriers or sleeve cylinders with quick change over Electrostatic assistance on station 1 to 7 by ACE |
