- Codice Macchina
- FL630
- Manufacturer
- UTECO
- Modello
- ONYX 107
- Year
- 2010
- Numero di colori
- 10
- Print possibilityes
- 10+0
- Gearless
- Yes
- Cambio a maniche rapido
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Larghezza nastro (mm)
- 1250
- Larghezza stampa (mm)
- 1200
- Min print repeat (mm)
- 330
- Max print repeat (mm)
- 800
- Unwinder type
- Turret automatic
- Diametro massimo svolgitore (mm)
- 800
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 800
- Essiccazione
- 2 zones , 4 fans , 5 mt tunnel , two gas burners 150.000 kcal /h
- Videocamera
- BST Premius digital with register control
- Guida film
- yes in and out
- Vyscosity control
- yes 8 automatic
- Washing system
- yes automatic wash up system for closed chamber doctor blades and anilox
- Sistema d'inchiostro
- Solvent based
- Anilox
- 10 anilox ceramic sleeves
- Maniche stampa
- to be agreed
- Ulteriori informazioni
- Mechanical speed 400m/min renovation 2020
Codice Macchina | FL630 |
Manufacturer | UTECO |
Modello | ONYX 107 |
Year | 2010 |
Numero di colori | 10 |
Print possibilityes | 10+0 |
Gearless | Yes |
Cambio a maniche rapido | Yes |
4 motor per deck CNC position system | Yes |
Computer supervision | Yes |
Larghezza nastro (mm) | 1250 |
Larghezza stampa (mm) | 1200 |
Min print repeat (mm) | 330 |
Max print repeat (mm) | 800 |
Unwinder type | Turret automatic |
Diametro massimo svolgitore (mm) | 800 |
Rewinder type | Turret automatic |
Max reel diameter rewinder (mm) | 800 |
Essiccazione | 2 zones , 4 fans , 5 mt tunnel , two gas burners 150.000 kcal /h |
Videocamera | BST Premius digital with register control |
Guida film | yes in and out |
Vyscosity control | yes 8 automatic |
Washing system | yes automatic wash up system for closed chamber doctor blades and anilox |
Sistema d'inchiostro | Solvent based |
Anilox | 10 anilox ceramic sleeves |
Maniche stampa | to be agreed |
Ulteriori informazioni | Mechanical speed 400m/min renovation 2020 |
