EXPERT DYNAMIC 10 Macchina da stampa flexo 10 colori // Flexo CI // Printing machines // Macchine Flexo Usate // Tecno Converting 2000 S.r.l.

Photo Gallery

Codice Macchina: FL1033
Manufacturer: EXPERT
Modello: DYNAMIC 10
Year: 2016
Numero di colori: 10
Print possibilityes: 10+0 , 5+5 , 10+10
Gearless: Yes
Cambio a maniche rapido: Yes
4 motor per deck CNC position system: Yes
Computer supervision: Yes
Larghezza nastro (mm): 1550
Larghezza stampa (mm): 1500
Min print repeat (mm): 540
Max print repeat (mm): 1250
Unwinder type: Turret Automatic auto splic e bidirectional
Diametro massimo svolgitore (mm): 1000
Rewinder type: Turret Automatic auto splic e bidirectional
Max reel diameter rewinder (mm): 1000
Essiccazione: 2 zones final tunnel 6 mt 2 gas burners
Videocamera: yes BST with auto register
Guida film: yes in and out
Vyscosity control: yes
Washing system: yes
Anilox: 24 ceramic anilox sleeves? N° 4 x 500 l/cm - 3,5 cm3/m2 ; 8 x 360 l/cm - 5 cm3/m2 ; 2 x 280 l/cm – 6,5 cm3/m2; 2 x 220 l/cm - 7 cm3/m2; ° 2 x 200 l/cm - 9 cm3/m2 ; 1 x 180 l/cm - 10 cm3/m2 ; 1 x 160 l/cm - 11 cm3/m2;3 x 140 l/cm - 12,5 cm3/m2 ; 2 x 80L/cm 13 cm3/m2
Ulteriori informazioni: Turning bar full width 5+5 Turning bar half width 10+10 Register control for reprint and driven infeed roll Plate mounter Plate washing machine Anilox wash machine Solvent distiller

Codice Macchina	FL1033
Manufacturer	EXPERT
Modello	DYNAMIC 10
Year	2016
Numero di colori	10
Print possibilityes	10+0 , 5+5 , 10+10
Gearless	Yes
Cambio a maniche rapido	Yes
4 motor per deck CNC position system	Yes
Computer supervision	Yes
Larghezza nastro (mm)	1550
Larghezza stampa (mm)	1500
Min print repeat (mm)	540
Max print repeat (mm)	1250
Unwinder type	Turret Automatic auto splic e bidirectional
Diametro massimo svolgitore (mm)	1000
Rewinder type	Turret Automatic auto splic e bidirectional
Max reel diameter rewinder (mm)	1000
Essiccazione	2 zones final tunnel 6 mt 2 gas burners
Videocamera	yes BST with auto register
Guida film	yes in and out
Vyscosity control	yes
Washing system	yes
Anilox	24 ceramic anilox sleeves? N° 4 x 500 l/cm - 3,5 cm3/m2 ; 8 x 360 l/cm - 5 cm3/m2 ; 2 x 280 l/cm – 6,5 cm3/m2; 2 x 220 l/cm - 7 cm3/m2; ° 2 x 200 l/cm - 9 cm3/m2 ; 1 x 180 l/cm - 10 cm3/m2 ; 1 x 160 l/cm - 11 cm3/m2;3 x 140 l/cm - 12,5 cm3/m2 ; 2 x 80L/cm 13 cm3/m2
Ulteriori informazioni	Turning bar full width 5+5 Turning bar half width 10+10 Register control for reprint and driven infeed roll Plate mounter Plate washing machine Anilox wash machine Solvent distiller
