- Codice Macchina
- FL979
- Manufacturer
- WINDMÖLLER & HÖLSCHER
- Modello
- PRIMAFLEX CS
- Year
- 2004
- Numero di colori
- 8
- Gearless
- Yes
- Cambio a maniche rapido
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Larghezza nastro (mm)
- 850
- Larghezza stampa (mm)
- 835
- Min print repeat (mm)
- 255
- Max print repeat (mm)
- 800
- Unwinder type
- Turret Automatic Nonstop with roll lifting platform . Web tension 25-270 N
- Diametro massimo svolgitore (mm)
- 800
- Rewinder type
- Turret Automatic Nonstop with roll unloading platform . Web tension 25- 300 N . Razor cut slitting unit adjustable every 5 mm with driven banana .
- Max reel diameter rewinder (mm)
- 800
- Essiccazione
- 2 zones 4 fans electric heaters . Automatic air recirculation system with ENPRO solvent concentration control
- Videocamera
- AVT Jupiter
- Trattamento Corona
- Driven Softal corona treater with antistatic bar
- Guida film
- 1 BST EKR 1500, webguide with motorized positioning of the edge sensor after unwinder and 1 BST EKR 1500 at rewinder
- Vyscosity control
- yes
- Sistema d'inchiostro
- Closed chamber doctor blades
- Anilox
- 21 ceramic anilox sleeves as follows; 4x 460 L/cm-volume 5; 3x 340 L/cm-vol 5 ;1x 255 L/cm-vol. 8,1; 3x 200 L/cm-vol. 8 ;
- Maniche stampa
- compressible sleeves with repeat length: 290, 300, 320, 340, 350, 360, 380, 400, 420, 430, 440, 450, 465, 490, 500, 520 and 560 (each repeat 8 sleeves)
- Cilindri stampa
- Adapters for flag thin and classic: 300, 320, 350, 360, 380, 400, 440 and 500 (variable numbers for each repeat length).
- Ulteriori informazioni
- SPARE ADDITIONAL PARTS 2 doctor chamber printing station 1-4 and 2 doctor chambers printing station 5-8 2 diaphragm pumps
| Codice Macchina | FL979 |
| Manufacturer | WINDMÖLLER & HÖLSCHER |
| Modello | PRIMAFLEX CS |
| Year | 2004 |
| Numero di colori | 8 |
| Gearless | Yes |
| Cambio a maniche rapido | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Larghezza nastro (mm) | 850 |
| Larghezza stampa (mm) | 835 |
| Min print repeat (mm) | 255 |
| Max print repeat (mm) | 800 |
| Unwinder type | Turret Automatic Nonstop with roll lifting platform . Web tension 25-270 N |
| Diametro massimo svolgitore (mm) | 800 |
| Rewinder type | Turret Automatic Nonstop with roll unloading platform . Web tension 25- 300 N . Razor cut slitting unit adjustable every 5 mm with driven banana . |
| Max reel diameter rewinder (mm) | 800 |
| Essiccazione | 2 zones 4 fans electric heaters . Automatic air recirculation system with ENPRO solvent concentration control |
| Videocamera | AVT Jupiter |
| Trattamento Corona | Driven Softal corona treater with antistatic bar |
| Guida film | 1 BST EKR 1500, webguide with motorized positioning of the edge sensor after unwinder and 1 BST EKR 1500 at rewinder |
| Vyscosity control | yes |
| Sistema d'inchiostro | Closed chamber doctor blades |
| Anilox | 21 ceramic anilox sleeves as follows; 4x 460 L/cm-volume 5; 3x 340 L/cm-vol 5 ;1x 255 L/cm-vol. 8,1; 3x 200 L/cm-vol. 8 ; |
| Maniche stampa | compressible sleeves with repeat length: 290, 300, 320, 340, 350, 360, 380, 400, 420, 430, 440, 450, 465, 490, 500, 520 and 560 (each repeat 8 sleeves) |
| Cilindri stampa | Adapters for flag thin and classic: 300, 320, 350, 360, 380, 400, 440 and 500 (variable numbers for each repeat length). |
| Ulteriori informazioni | SPARE ADDITIONAL PARTS 2 doctor chamber printing station 1-4 and 2 doctor chambers printing station 5-8 2 diaphragm pumps |
