- Codice Macchina
- FL921
- Manufacturer
- SCHIAVI
- Modello
- ALPHA
- Year
- 2001
- Numero di colori
- 8
- Gearless
- Yes
- Cambio a maniche rapido
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Larghezza nastro (mm)
- 1250
- Larghezza stampa (mm)
- 1200
- Min print repeat (mm)
- 325
- Max print repeat (mm)
- 650
- Unwinder type
- TURRET
- Diametro massimo svolgitore (mm)
- 1000
- Rewinder type
- TURRET
- Max reel diameter rewinder (mm)
- 1000
- Essiccazione
- 2 zones, 4 fans and 2 thermal oil heat exchangers. 1 zone inter colors 8.500m3/h, second zone is drying tunnel 10.300 m3/h: 2 x 18 nozels, tot 4,5 m length, Infrared lamps
- Videocamera
- BST
- Trattamento Corona
- yes
- Guida film
- 2 in and out
- Vyscosity control
- New celio
- Sistema d'inchiostro
- Closed chamber doctor blades
- Maniche stampa
- approx 310 sleeves + approx 24 bridge sleeves/adapters
- Ulteriori informazioni
- CI drum diam 1800mm Hastelly surface Materials: Film from 10 my, Alu foil from 7 my, paper and laminates up to 120 gsm Plate thickness 1,14mm + 0,55mm Thermo regulation for CI drum LEL contol system Zellweger speed 350 m/min
| Codice Macchina | FL921 |
| Manufacturer | SCHIAVI |
| Modello | ALPHA |
| Year | 2001 |
| Numero di colori | 8 |
| Gearless | Yes |
| Cambio a maniche rapido | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Larghezza nastro (mm) | 1250 |
| Larghezza stampa (mm) | 1200 |
| Min print repeat (mm) | 325 |
| Max print repeat (mm) | 650 |
| Unwinder type | TURRET |
| Diametro massimo svolgitore (mm) | 1000 |
| Rewinder type | TURRET |
| Max reel diameter rewinder (mm) | 1000 |
| Essiccazione | 2 zones, 4 fans and 2 thermal oil heat exchangers. 1 zone inter colors 8.500m3/h, second zone is drying tunnel 10.300 m3/h: 2 x 18 nozels, tot 4,5 m length, Infrared lamps |
| Videocamera | BST |
| Trattamento Corona | yes |
| Guida film | 2 in and out |
| Vyscosity control | New celio |
| Sistema d'inchiostro | Closed chamber doctor blades |
| Maniche stampa | approx 310 sleeves + approx 24 bridge sleeves/adapters |
| Ulteriori informazioni | CI drum diam 1800mm Hastelly surface Materials: Film from 10 my, Alu foil from 7 my, paper and laminates up to 120 gsm Plate thickness 1,14mm + 0,55mm Thermo regulation for CI drum LEL contol system Zellweger speed 350 m/min |
