- Codice Macchina
- FL803
- Manufacturer
- UTECO
- Modello
- EMERALD 107
- Year
- 2003
- Numero di colori
- 10
- Print possibilityes
- 10+Solventless lamination
- Rinnovo
- Major overhaul during 2016-1017, new washing system, new chamber doctor blades, new viscosity control, new videocamera, check up of bearings, mandrels re-balancing, part of sleeves and aniloxes were bought new in 2017.
- Gearless
- Yes
- Cambio a maniche rapido
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Larghezza nastro (mm)
- 1250
- Larghezza stampa (mm)
- 1200
- Min print repeat (mm)
- 350
- Max print repeat (mm)
- 800
- Unwinder type
- Turret automatic
- Diametro massimo svolgitore (mm)
- 1000
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 800
- Essiccazione
- 2 drying zones- 4 fans- final tunnel 6 mt length, hot water heat exchangers , automatic recirculation system with Heck controll
- Videocamera
- yes BST Eltromat new 2016, secon bd video camera E&L for back side inspection
- Trattamento Corona
- yes two Corona treaters F&B one before printing , second for secondary unwinder for material to be laminated
- Guida film
- yes
- Vyscosity control
- yes new Gama 2017
- Washing system
- yes
- Sistema d'inchiostro
- doctor blades - new 2016
- Anilox
- 40 ceramic anilox sleeves
- Maniche stampa
- 800 totally
- Ulteriori informazioni
- 10 color CI with solventless lamination in line
| Codice Macchina | FL803 |
| Manufacturer | UTECO |
| Modello | EMERALD 107 |
| Year | 2003 |
| Numero di colori | 10 |
| Print possibilityes | 10+Solventless lamination |
| Rinnovo | Major overhaul during 2016-1017, new washing system, new chamber doctor blades, new viscosity control, new videocamera, check up of bearings, mandrels re-balancing, part of sleeves and aniloxes were bought new in 2017. |
| Gearless | Yes |
| Cambio a maniche rapido | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Larghezza nastro (mm) | 1250 |
| Larghezza stampa (mm) | 1200 |
| Min print repeat (mm) | 350 |
| Max print repeat (mm) | 800 |
| Unwinder type | Turret automatic |
| Diametro massimo svolgitore (mm) | 1000 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 800 |
| Essiccazione | 2 drying zones- 4 fans- final tunnel 6 mt length, hot water heat exchangers , automatic recirculation system with Heck controll |
| Videocamera | yes BST Eltromat new 2016, secon bd video camera E&L for back side inspection |
| Trattamento Corona | yes two Corona treaters F&B one before printing , second for secondary unwinder for material to be laminated |
| Guida film | yes |
| Vyscosity control | yes new Gama 2017 |
| Washing system | yes |
| Sistema d'inchiostro | doctor blades - new 2016 |
| Anilox | 40 ceramic anilox sleeves |
| Maniche stampa | 800 totally |
| Ulteriori informazioni | 10 color CI with solventless lamination in line |
