8 colors FISCHER & KRECKE 20 SIX (GEARLESS) Флексографской печатной машины ** SOLD ** Ask more informations About a Similar One

Machine code FL629
Manufacturer FISCHER & KRECKE
Model 20 SIX (GEARLESS)
Year 2013
Number of colors 8
Gearless Yes
Fast sleeve change Yes
Web width (mm) 1100
Print width (mm) 1050
Max reel diameter unwinder (mm) 1020
Rewinder type Non stop
Drying electric
Videocamera Yes
Corona treatment AFS
Web guides Yes
Inking system 4 carrier for doctor blade for print decks inside the CI. 4 carrier for doctor blade for print decks outside the CI. 8 doctor blade chamber with quick change system.
Anilox 15 anilox 1X 120L 14,0 CM ; 140L 9,5 CM; 160L 11,0 CM; 180L 8,0 CM; 180 L 23,0 CM; 2X 260 L 5,0 CM ; 360 L 4,5 CM; 360 L 5,5 CM; 1 X400L 3,5 CM; GGT M 5,0 , GTT S 2,5 CM ; GTT XS 1, 5 CM
Print Sleeves Plate cylinders as follows: 28 sets (270 pcs) 340 mm ? 8 pcs ; 350 mm ? 12 pcs; 360 mm ? 12 pcs ;370 mm ? 8 pcs ;380 mm - 16 pcs ;400 mm ? 16 pcs;410 mm ? 8 pcs;420 mm - 16 pcs;430 mm ? 8 pcs;440 mm ? 8 pcs ;450 mm ? 8 pcs;460 mm ? 8 pcs; 470 mm ? 8 pcs;480 mm ? 16 pcs ;500 mm - 8 pcs;520 mm - 8 pcs;530 mm ? 8 pcs;540 mm ? 8 pcs;550 mm ? 8 pcs;560 mm ? 8 pcs;570 mm ? 8 pcs;580 mm ? 8 pcs;600 mm - 8 pcs;610 mm - 8 pcs;620 mm ? 14 pcs;640 mm ? 8 pcs;650 mm - 8 pcs;660 mm ? 8 pcs
Additional information Mechanical speed max 400m/min Web break detector system Antistatic unit with 2 antistatic bars in front of CI unit Gearless water cooled CI torque drive Plate mounting system SMART GPS LEL monitoring system Web threading system Chill roll unit with nip roll UPS System (Uninterrupted Power supply ) Smart Graphic positioning system 8 pneumatic pumps; Dimentions (mm): L ? 15787, W ? 5500 (with open doors), H ? 4980 Weight (kg): 57000

** SOLD **
