- Codice Macchina
- SA51
- Manufacturer
- FISCHER & KRECKE
- Year
- 1980
- Rinnovo
- Machine is renovated in 2020 with new touch screen control system: Can changing size without wheels - digitally. New rubber printing rollers. New counter and electric.
- Tipologia
- Tuber
- Sack dimensions (mm)
- Tube width - 35-64 cm Tube length - 50-145 cm Max.Reel diameter - 135 cm
- Ulteriori informazioni
- Max. Reel width - 160 cm 3 layer stand with krane system. 1 web guide unit with fife system. 3 cross glue unit for 3 ply 1 microperforation unit - can drill paper tube for air circulation, (drilling apparatus) 1 print unit with 2 colors 1 glue unit with folding unit 1 cuting unit - straight cutting 1 new photocell system - 2020 1 new system for digitally cutting tubes. The size changed by touch screen display. On the machine is installed 3 unwinders.
| Codice Macchina | SA51 |
| Manufacturer | FISCHER & KRECKE |
| Year | 1980 |
| Rinnovo | Machine is renovated in 2020 with new touch screen control system: Can changing size without wheels - digitally. New rubber printing rollers. New counter and electric. |
| Tipologia | Tuber |
| Sack dimensions (mm) | Tube width - 35-64 cm Tube length - 50-145 cm Max.Reel diameter - 135 cm |
| Ulteriori informazioni | Max. Reel width - 160 cm 3 layer stand with krane system. 1 web guide unit with fife system. 3 cross glue unit for 3 ply 1 microperforation unit - can drill paper tube for air circulation, (drilling apparatus) 1 print unit with 2 colors 1 glue unit with folding unit 1 cuting unit - straight cutting 1 new photocell system - 2020 1 new system for digitally cutting tubes. The size changed by touch screen display. On the machine is installed 3 unwinders. |
