- Codice Macchina
- FL1207
- Manufacturer
- WINDMÖLLER & HÖLSCHER
- Modello
- Primaflex
- Year
- 2005
- Numero di colori
- 8
- Gearless
- Yes
- Cambio a maniche rapido
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Larghezza nastro (mm)
- 870
- Larghezza stampa (mm)
- 820
- Min print repeat (mm)
- 250
- Max print repeat (mm)
- 800
- Unwinder type
- Turret automatic
- Diametro massimo svolgitore (mm)
- 800
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 800
- Essiccazione
- 2 zones, 4 fans , final tunnel, Gas burners
- Videocamera
- BST Premius
- Guida film
- 2 web guides
- Anilox
- 22 aniloxes : 1 x 120 lines 12, 8 cm³/m², 1 x 140 lines 13, 5 , 1 x 140 lines 16,5 , 1 x 140 lines 13,4 cm³/m², 1 x 160 lines 12, 3 , 1 x 160 lines 11 cm³/m² 1 x 200 lines 9,5 , 1 x 200 lines 10 , 1 x 200 lines 9,5 cm³/m² 1 x 280 lines 10 cm³/m² 1 x 300 lines 7, 3 cm³/m², 1 x 360 lines 4, 8 , 1 x 360 lines 5 cm, 2 x 360 lines 4, 9 , 1 x 360 lines 8 cm³/m² 3 x 400 lines 4, 5 cm³/m², 1 x 400 lines 4, 6 cm³/m², 1 x 460 lines 5 cm³/m², 1 x 580 lines 4 cm³/m²,
- Maniche stampa
- 378 sleeves, 16 x 250mm, 16 x 260mm, 8 x 270mm, 8 x 280mm, 8 x 290mm, 8 x 300mm, 8 x 310mm, 8 x 320mm, 8 x 330mm, 8 x 340mm, 8 x 345mm, 16 x 350mm, 8 x 360mm, 8 x 375mm, 8 x 380mm, 16 x 390mm, 16 x 400mm, 8 x 410mm, 16 x 420mm, 16 x 430mm, 8 x 440mm, 8 x 450mm, 8 x 460mm, 8 x 470mm, 8 x 480mm, 8 x 490mm, 8 x 500mm, 8 x 520mm, 8 x 560mm, 8 x 580mm, 10 x 600mm, 8 x 610mm, 8 x 620mm, 8 x 640mm, 8 x 650mm, 8 x 680mm, 8 x 700mm, 8 x 730mm, 8 x 750mm
| Codice Macchina | FL1207 |
| Manufacturer | WINDMÖLLER & HÖLSCHER |
| Modello | Primaflex |
| Year | 2005 |
| Numero di colori | 8 |
| Gearless | Yes |
| Cambio a maniche rapido | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Larghezza nastro (mm) | 870 |
| Larghezza stampa (mm) | 820 |
| Min print repeat (mm) | 250 |
| Max print repeat (mm) | 800 |
| Unwinder type | Turret automatic |
| Diametro massimo svolgitore (mm) | 800 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 800 |
| Essiccazione | 2 zones, 4 fans , final tunnel, Gas burners |
| Videocamera | BST Premius |
| Guida film | 2 web guides |
| Anilox | 22 aniloxes : 1 x 120 lines 12, 8 cm³/m², 1 x 140 lines 13, 5 , 1 x 140 lines 16,5 , 1 x 140 lines 13,4 cm³/m², 1 x 160 lines 12, 3 , 1 x 160 lines 11 cm³/m² 1 x 200 lines 9,5 , 1 x 200 lines 10 , 1 x 200 lines 9,5 cm³/m² 1 x 280 lines 10 cm³/m² 1 x 300 lines 7, 3 cm³/m², 1 x 360 lines 4, 8 , 1 x 360 lines 5 cm, 2 x 360 lines 4, 9 , 1 x 360 lines 8 cm³/m² 3 x 400 lines 4, 5 cm³/m², 1 x 400 lines 4, 6 cm³/m², 1 x 460 lines 5 cm³/m², 1 x 580 lines 4 cm³/m², |
| Maniche stampa | 378 sleeves, 16 x 250mm, 16 x 260mm, 8 x 270mm, 8 x 280mm, 8 x 290mm, 8 x 300mm, 8 x 310mm, 8 x 320mm, 8 x 330mm, 8 x 340mm, 8 x 345mm, 16 x 350mm, 8 x 360mm, 8 x 375mm, 8 x 380mm, 16 x 390mm, 16 x 400mm, 8 x 410mm, 16 x 420mm, 16 x 430mm, 8 x 440mm, 8 x 450mm, 8 x 460mm, 8 x 470mm, 8 x 480mm, 8 x 490mm, 8 x 500mm, 8 x 520mm, 8 x 560mm, 8 x 580mm, 10 x 600mm, 8 x 610mm, 8 x 620mm, 8 x 640mm, 8 x 650mm, 8 x 680mm, 8 x 700mm, 8 x 730mm, 8 x 750mm |
