- Codice Macchina
- FL1152
- Manufacturer
- UTECO
- Modello
- DIAMOND HP 108
- Year
- 2011
- Numero di colori
- 10
- Print possibilityes
- 10+0, 10+10
- Rinnovo
- a retrofit of the electronic parts and a 100x100 print inspection carried out in 2019.
- Gearless
- Yes
- Cambio a maniche rapido
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Larghezza nastro (mm)
- 1550
- Larghezza stampa (mm)
- 1500
- Min print repeat (mm)
- 420
- Max print repeat (mm)
- 870
- Unwinder type
- Turret automatic
- Diametro massimo svolgitore (mm)
- 1000
- Rewinder type
- Turret automatic
- Max reel diameter rewinder (mm)
- 1000
- Essiccazione
- 2 zones 4 fans with 6 mt final tunnel and thermo oil heat exchangers
- Videocamera
- GRAFYKONTROL
- Guida film
- yes, BST
- Vyscosity control
- Yes
- Washing system
- Yes, automatic
- Sistema d'inchiostro
- Closed chamber doctor blades
- Anilox
- 16
- Maniche stampa
- 50
- Ulteriori informazioni
- Printing speed max 600 mpm Carbon fiber mandrels Automatic printing set up and automatic register control with "click and drag" system by GRAFYKONTROL Drum cleaning device 100x100 defect control by Grafikontrol Turning bar 10+10 half width
| Codice Macchina | FL1152 |
| Manufacturer | UTECO |
| Modello | DIAMOND HP 108 |
| Year | 2011 |
| Numero di colori | 10 |
| Print possibilityes | 10+0, 10+10 |
| Rinnovo | a retrofit of the electronic parts and a 100x100 print inspection carried out in 2019. |
| Gearless | Yes |
| Cambio a maniche rapido | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Larghezza nastro (mm) | 1550 |
| Larghezza stampa (mm) | 1500 |
| Min print repeat (mm) | 420 |
| Max print repeat (mm) | 870 |
| Unwinder type | Turret automatic |
| Diametro massimo svolgitore (mm) | 1000 |
| Rewinder type | Turret automatic |
| Max reel diameter rewinder (mm) | 1000 |
| Essiccazione | 2 zones 4 fans with 6 mt final tunnel and thermo oil heat exchangers |
| Videocamera | GRAFYKONTROL |
| Guida film | yes, BST |
| Vyscosity control | Yes |
| Washing system | Yes, automatic |
| Sistema d'inchiostro | Closed chamber doctor blades |
| Anilox | 16 |
| Maniche stampa | 50 |
| Ulteriori informazioni | Printing speed max 600 mpm Carbon fiber mandrels Automatic printing set up and automatic register control with "click and drag" system by GRAFYKONTROL Drum cleaning device 100x100 defect control by Grafikontrol Turning bar 10+10 half width |
