- Codice Macchina
- FL1141
- Manufacturer
- FLEXOTECNICA
- Modello
- CHRONOS
- Year
- 2006
- Numero di colori
- 10
- Print possibilityes
- 10+0
- Gearless
- Yes
- Cambio a maniche rapido
- Yes
- 4 motor per deck CNC position system
- Yes
- Computer supervision
- Yes
- Larghezza nastro (mm)
- 1250
- Larghezza stampa (mm)
- 1220
- Min print repeat (mm)
- 330
- Max print repeat (mm)
- 800
- Unwinder type
- Turret Automatic
- Diametro massimo svolgitore (mm)
- 800
- Rewinder type
- Turret Automatic
- Max reel diameter rewinder (mm)
- 800
- Essiccazione
- 2 Drying zones, 4 fans, 3,5 mt final tunnel , 2 Gas burners , automatic air
- Videocamera
- Yes BST Premius 3 ccd
- Guida film
- yes in and out
- Vyscosity control
- Yes
- Washing system
- Yes
- Sistema d'inchiostro
- Closed chamber doctor blades and ceramic anilox rollers N°10 Ink Pumps.
- Anilox
- 25 ceramic anilox sleeves
- Maniche stampa
- 264 sleeves , 10 for each following repeat 330 mm, 340 , 350 , 360 , 370 , 380 ,390 , 400 , 410 , 420 , 430 , 440 , 450 ,460 , 470 , 480 , 500 , 520 , 530 , 540 , 550 , 560 , 600 , 620 , 640 . repeats 660 x 8 , 770 x 6 ,
- Ulteriori informazioni
- Plate mounter BIEFFEBI
| Codice Macchina | FL1141 |
| Manufacturer | FLEXOTECNICA |
| Modello | CHRONOS |
| Year | 2006 |
| Numero di colori | 10 |
| Print possibilityes | 10+0 |
| Gearless | Yes |
| Cambio a maniche rapido | Yes |
| 4 motor per deck CNC position system | Yes |
| Computer supervision | Yes |
| Larghezza nastro (mm) | 1250 |
| Larghezza stampa (mm) | 1220 |
| Min print repeat (mm) | 330 |
| Max print repeat (mm) | 800 |
| Unwinder type | Turret Automatic |
| Diametro massimo svolgitore (mm) | 800 |
| Rewinder type | Turret Automatic |
| Max reel diameter rewinder (mm) | 800 |
| Essiccazione | 2 Drying zones, 4 fans, 3,5 mt final tunnel , 2 Gas burners , automatic air |
| Videocamera | Yes BST Premius 3 ccd |
| Guida film | yes in and out |
| Vyscosity control | Yes |
| Washing system | Yes |
| Sistema d'inchiostro | Closed chamber doctor blades and ceramic anilox rollers N°10 Ink Pumps. |
| Anilox | 25 ceramic anilox sleeves |
| Maniche stampa | 264 sleeves , 10 for each following repeat 330 mm, 340 , 350 , 360 , 370 , 380 ,390 , 400 , 410 , 420 , 430 , 440 , 450 ,460 , 470 , 480 , 500 , 520 , 530 , 540 , 550 , 560 , 600 , 620 , 640 . repeats 660 x 8 , 770 x 6 , |
| Ulteriori informazioni | Plate mounter BIEFFEBI |
